Discontinued Product
Global Fire VULCAN 2 VOX Addressable Base Voice Sounder (White) (VOX-A-VULCAN2-S)
Discontinued
Alternative Products
Product Details for Global Fire VULCAN 2 VOX Addressable Base Voice Sounder (White) (VOX-A-VULCAN2-S)
The Global Fire VULCAN 2 VOX A is a ceiling-mounted addressable voice sounder in a white casing. Normally the VULCAN 2 VOX will be used in conjunction with a detector, however a lid is available as an option. Up to 32 individually addressed sounders can be installed per loop, using the address range 94 to 125. It can also be configured in shadow mode.
With message selection directly programmable via the standard sounder programming of GFE fire alarm control panels, the VULCAN 2 VOX A can broadcast up to five differentiated pre-loaded messages: Alert, Fire, Evacuation, Test and a Silence Message. The desired messages can be downloaded from our own proprietary recording PC application (VOX LOADER) via a standard USB interface. This product is exclusively loop powered and controlled.
Key Features of the VOX-A-VULCAN2-S |
|---|
|
> Ceiling mounted
> Addressable Base Voice Sounder > White housing > Up to 32 individually addressed sounders per loop (addresses 94 - 125) > Can be configured in shadow mode > Set address using switches 1 - 5 of 8-way DIL switch > 5 pre-loaded messages (Alert, Fire, Evacuation, Test and Silence Message) > Loop controlled and loop powered > 92 dBA maximum sounder output @ 1m > Programme messages via USB i/face using dedicated software > Compatible with all GFE Chameleon panels |
| Brand | Global Fire Equipment |
|---|---|
| Manufacturer Part No. | VOX-A-VULCAN2-S |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | GFE ZEOS |
| Colour | White |
| Warranty | 10 Years |
FAQ’s for Global Fire VULCAN 2 VOX Addressable Base Voice Sounder (White) (VOX-A-VULCAN2-S)
Product Specification for Global Fire VULCAN 2 VOX Addressable Base Voice Sounder (White) (VOX-A-VULCAN2-S)
| Product code: | VOX-A-VULCAN2-S |
| Dimensions: |
D: 100mm x H:29mm |
| Supply voltage: |
Loop powered - 20V to 30V DC |
| Loop Current - Quiescent: |
0.7 mA; 7.5 mA max. (sounder active or charging) |
| Loop current - Alarm Beacon: | 1.4mA |
| Sounder output @ 1m: | Tone 90 dBA - Voice Message 94 dBA |
| Total audio memory size: |
4 mins (decoded audio) up to 16 mins (encoded audio) |
| Protection: | IP21C - Type A - Indoor use |
| Operation temperature: | -10oC to +55oC |
| Max. cable size: | 2.5mm2 |
| Max. humidity: | 95% RH Non-Condensing |
| Colour / case material: | White / ABS & Transparent PC |
| Weight: | 120g incl. base, 120 - 140g with lid |
