Hochiki CHQ-CP2 Addressable Call Point PCB
SKU
CHQ-CP2
£28.79
£23.99
Hochiki CHQ-CP2 Addressable Call Point PCB
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Hochiki CHQ-CP2 Addressable Call Point PCB
The Hochiki CHQ-CP2 is a replacement PCB for Hochiki addressable manual call points. PCB only.
Key Features of the CHQ-CP2 |
|---|
|
> Call point PCB
> Replacement part > Hochiki addressable MCPs |
| Brand | Hochiki |
|---|---|
| Manufacturer Part No. | CHQ-CP2 |
| Product Series | Hochiki ESP |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Hochiki ESP |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Hochiki CHQ-CP2 Addressable Call Point PCB
No questions yet. Be the first to ask the question!
Product Specification for Hochiki CHQ-CP2 Addressable Call Point PCB
| Description | Hochiki Single Input Monitor |
| Product Code | CHQ-CP2 |
| Dimensions: | 44.5mm x 36.5mm |
| Features: | - Single un-monitored input - Non-polarised loop connections - Sleep mode for low power consumption - Monitor LED (when fitted) - flashes when unit is polled, continuously illuminated in alarm |
| Supply voltage: | Loop voltage (low) 17 - 31V |
| Current consumption (loop): | Quiescent: 230 µA (typ) Sleep mode: 38 µA (typ) Loop current (polled): 22 mA ± 20% Loop current (alarm): 5 mA |
| ON threshold level: | < 50Ω |
| OFF threshold level: | < 100Ω |
| Operating temperature: | -10oC to +50oC |
| Storage temperature: | -30oC to +60oC (<80% RH at 60oC) |
| Relative humidity: | 95% RH at 40C non-condensing * |
| Weight (g): | 15g (not including casing) |
| *Only applies when module is suitably housed | |
