GENT S-Quad Addressable Heat Detector with Voice Sounder & High Power Red VAD (S4-720-V-VAD-HPR)
Product Details for GENT S-Quad Addressable Heat Detector with Voice Sounder & High Power Red VAD (S4-720-V-VAD-HPR)
The GENT S4-720-V-VAD-HPR Addressable Heat Sensor with Integrated Voice Sounder and VAD combines renowned advanced sensing technology with state-of-the-art visual alarms. The only practical solution meeting the demands of detection and the performance needed to meet the EN54 part 23 standard.
The S4-720-V-VAD-HPR has a High-intensity VAD with three intensity settings to achieve maximum flexibility for different room coverage, optimising loop coverage. The Red VAD uses multiple red LEDs giving a true red colour.
The speech function is provided by stored messages on a non-volatile flash memory component. This audible output from the flash memory can hold up to 20 seconds of speech. There is also the capability to provide complex tones, such as bell and DIN tones. Each sensor includes four standard messages with the component, which are as follows:
• Alert Message: (Female Voice) “An incident has been reported in the building, please await further instructions”
• Alarm Message 1: (Female Voice) “Attention please, this is an emergency please leave the building by the nearest available exit”
• Alarm Message 2: (Male Voice) “This is a Fire Alarm! Please leave the building immediately by the nearest available exit”
• Test Message: (Female Voice) “This is a test message, no action is required”
Key Features of the S4-720-V-VAD-HPR |
|---|
|
> Sensor and alarm in one device reduces installation time and cost
> Built-in high-intensity VAD helps alert occupants in noisy environments as well as the hard of hearing > Red VADs use multiple red LEDs giving a true red colour > Meets all the requirements of the Equality Act 2010 > Compatible with the S-Cubed wall-mounted VAD > State-of-the-art, high-efficiency visual alarm technology > Advanced power management that increases loop capacity and integrity > Light output that allows devices to be sited at standard smoke and heat detector spacings > Synchronised flash rate across the whole control panel avoiding risk of induced seizures > VAD can operate independently of the sounder if required > Meets the requirements of BS5839 part 1 relating to sensitivity to epilepsy |
| Brand | GENT |
|---|---|
| Manufacturer Part No. | S4-720-V-VAD-HPR |
| Product Series | S-Quad |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | GENT |
| Sensor Type | Thermistor |
| Detectable Medium | Heat |
| Colour | White |
| Warranty | N/A |
FAQ’s for GENT S-Quad Addressable Heat Detector with Voice Sounder & High Power Red VAD (S4-720-V-VAD-HPR)
Product Specification for GENT S-Quad Addressable Heat Detector with Voice Sounder & High Power Red VAD (S4-720-V-VAD-HPR)
| Model: | S4-720-V-VAD-HPR GENT S4 Heat Sensor Voice Sounder, High Performance, Red VAD |
| Dimensions: | Diameter: 117mm (140mm with base and IP21 plate) x D:49.6mm (63.8mm with base) |
| Quantity of Sounder VADs per loop (guidance only): | High performance: High intensity - up to 45 Medium intensity - up to 60 Low intensity - up to 100 |
| Strobe colour: | Red |
| VAD Category - High Performance: | Power settings: High - C-3-14 (Also Open Category C-4.5-14) Medium - C-3-13 (Also Open Category C-4-13) Low - C-3-10 |
| Approvals: | EN54-23, BS5839 part 1 |
| IP Rating: | IP21 when used with IP Sensor Base S4-701 |
| Operating temperature: | -10 to +50°C |
| Body Colour: | White |
| Weight: | ca.110g (170g with base) |
