Discontinued Product
This product has been discontinued and is no longer available for purchase. Please contact us for further information and advice on suitable alternatives.
Ziton ZP2 - 1 Loop addressable panel + Fire Brigade Controls - Small Cabinet
SKU
ZP2-F1-FB2-S-99
Ziton Addressable Fire Panel with Fire Brigade controls - 1 Loop small cabinet (ZP2-F1-FB2-S-99)
Discontinued
Product Details for Ziton ZP2 - 1 Loop addressable panel + Fire Brigade Controls - Small Cabinet
The Ziton ZP2-F1-FB2-S-99 Addressable 1-Loop Fire Panel with user interface, fire brigade and fire protection controls. The single loop supports up to 128 devices in 512 zones. 2 supervised sounder/fire-routing outputs can also be used as freely programmable outputs. 2 conventional relay outputs and 2 supervised outputs, working in pairs and dedicated to common fire and fault conditions, and 2 user configurable inputs for monitoring and control are available. Housed in a small cabinet.
Key Features of the ZP2-F1-FB2-S-99 |
|---|
|
> 1 loop with up to 512 zones with Fire Brigade & Fire Protection controls and 300 output groups
> Up to 24 LED Zone indicators for Fire and Fault with space for a 4 digit number > Auto configuration, setup wizards and default EN54 setup modes > Ethernet port with TCP/IP for remote diagnostics, maintenance and programming > EN54 compliant graphical LCD with icons and up to 256 zones > Jog Dial with 4 soft buttons for simple and intuitive user control > Pleasing design with special paintable synthetic door > Easy removable door and chassis for quick and clean installation > All pluggable connectors > 3 USB ports with memory stick support and RS232 for printer support > Email notification for events directly from the panel (4 user accounts) > Auxiliary 24VDC supply output with reset support > 3 operator level menu structure (20 usernames and passwords) > History log memory for 9999 events > Up to 24 hours standby time and 30 minutes alarm > Compatible with the new loop powered sounders/beacons and base sounders and the 2000 series detectors with replaceable optical chamber |
| Brand | Ziton |
|---|---|
| Manufacturer Part No. | ZP2-F1-FB2-S-99 |
FAQ’s for Ziton ZP2 - 1 Loop addressable panel + Fire Brigade Controls - Small Cabinet
No questions yet. Be the first to ask the question!
Product Specification for Ziton ZP2 - 1 Loop addressable panel + Fire Brigade Controls - Small Cabinet
| Code: | ZP2-F1-FB2-S-99 |
| Description: | Ziton Addressable Fire Panel with Fire Brigade controls - 1 Loop small cabinet |
| Dimensions: | W:410mm x H:298mm x D:162mm |
| Form factor: | Small |
| Max. system capacity: | up to 8128 devices |
| Network size (nodes): | up to 64 |
| Max. zone capacity: | up to 512 |
| Operating voltage: | 110 /230 VAC (+10%/-15%) 50 / 60 Hz (±5%) |
| Max. loop capacity: | 1 |
| Outputs: | 1, 250 mA / 29 VDC (29 to 36 VDC ) |
| Cable length: | 56 ohm / 1 µF max. 2 km |
| Cable type: | Recommended 2 core 1.5 mm² twisted pair |
| Current consumption: | Nom. 0.6 / 1.3 A, Max. 1.5 / 3.15 A |
| INPUT | |
| Programmable: | 2 |
| Cable type: | Recommended 2 core 1.5 mm² twisted pair |
| Termination: | 15kohm |
| Max. load: | 150 mA |
| OUTPUT | |
| Programmable supervised: | 2, 750 mA / 19.5 to 28 VDC (24 VDC nominal) |
| General Fire + Fault supervised: | 2, 350mA / 19.5-28VDC (24 VDC nominal) |
| General Fire + Fault relay: | 2 |
| Aux: | 1 resettable, 500mA / 19.5-28VDC (24VDC nominal) |
| Cable type: | Recommended 2 core 1.5 mm² twisted pair |
| Termination: | 15 kohm |
| Standby battery capacity: | Max. 2 x 12V/7.2Ah (use supplied cables) |
| Mains fuse rating: | 2 / 4 A |
| Mains cable type: | 3 x 1.5 mm² (live, neutral, earth) |
| Operating temperature: | -5 to +40°C |
| Relative humidity: | 95% max. non condensing |
| Storage temperature: | -10 to +50°C |
| IP rating: | IP30, Indoor use |
| Mounting: | Surface |
| Cable entries: | 9 (20mm) / 2 (20mm) / 2 removable plates (Top/Bottom/Back) |
| Colour: | Grey (RAL 7035) |
| Regulatory: | BS5839-1, CPD, LPCB, NBNS21-100, NEN2535, RoHS, WEEE compliant EN54-13, EN54-2, EN54-21, EN54-4, VdS certified |
| Weight: | 6.6kg (5.2kg without battery) |
