Ziton ZP1 Network Interface
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Ziton ZP1 Network Interface
The Ziton 2010-1-NB RS485 FireNet network interface allows networking between conventional and addressable panels. Create a bus mode class-B, or redundant class-A, 32 node network, supporting up to 64 zones. Each node may be a fire panel or a fire panel repeater. When optical fibre is preferred, cable lengths above 1200 m between nodes are required, or in cases where high levels of EMC are expected, a standard RS485 to fibre converter may be used.
Key Features of the 2010-1-NB |
|---|
|
> Class A or B network support
> Up to 1200 m between nodes > May be used for panels and repeaters > Up to 32 nodes / 64 zones > Pluggable connectors > Connects directly to the main board > Allows networking between conventional and addressable panels |
| Brand | Ziton |
|---|---|
| Manufacturer Part No. | 2010-1-NB |
Write Your Own Review
FAQ’s for Ziton ZP1 Network Interface
No questions yet. Be the first to ask the question!
Product Specification for Ziton ZP1 Network Interface
| Code: | 2010-1-NB |
| Description: | Ziton Conventional Fire Panel Accessory - Network Interface |
| Dimensions: | W:100mm x H:30mm x D:150mm |
| Form factor: | Small |
| Network size: | up to 32 nodes |
| Distance between nodes: | 1200m max. |
| Operating mode: | Class A or B |
| Medium: | Copper |
| Protocol: | Proprietary |
| Mounting: | In cabinet |
| Operating temperature: | -8°C to 42°C |
| Storage temperature: | -10 to 50°C |
| Relative humidity: | 95% non-condensing max. |
| Weight: | 130g (40g net) |
