Ziton Weatherproof Heat Detector 87°C, Class CS

The Ziton Enclosed Conventional Heat Detector, Weatherproof IP67, 87°C, Class CS (84 to 100°C) is normally used in rooms where the temperature can be expected to rise rapidly in case of a fire or in places where smoke detectors cannot be used. It is intended for outdoor or indoor use in high humidity areas.

A conventional fixed temperature heat detector, i.e. it will give an alarm within a response temperature range in accordance with EN54-5:2000. The sensing element is a heat pick-up shield and a bi-metal switch. An LED on the detector will light up when the detector activates. Supports an output for a remote indicator.

The detector is latching, i.e. it will not be automatically reset if the temperature, after the alarm, falls below the detector's static response temperature. An LED and a connected remote LED will be lit until the detector is reset via the C.I.E.

All electronic components are mounted in a grey waterproof detector housing and fitted to the supplied connection box. The connection box has three cable inlets. Three compression glands and a silicon gasket for IP67 protection are supplied with the product. 3 pairs of flying leads with female push-on connectors to connect the zone line cables (in / out) and the remote indicator are provided.
