Zeta SmartConnect Multi-Loop Touchscreen Repeater Panel (SMART/REP)
Product Details for Zeta SmartConnect Multi-Loop Touchscreen Repeater Panel (SMART/REP)
The Zeta SMART/REP Multi-loop Repeater can be used to monitor, operate and program Smart Multi-loop control panels (FACPs) from anywhere within the networked system.
The repeater features a 4.3” colour touch screen display that provides easy-to-understand system messages and has an LED, button and menu set up that mirrors a Smart Multi-loop control panel.
Operates as part of a networked system of up to 64 panels, peer-to-peer, with programming options that allow configurable control over whether messages from specific panels are transmitted around the network or remain local.
The Smart Multi-loop Repeater is supplied with a black finish to match virtually any décor. The repeater enclosure can be surface or flush mounted.
Key Features of the SMART/REP |
|---|
|
> 4.3” colour touch screen display
> 8032 Event Log > Up to 64 panel peer-to-peer network > 13 status LED indicators > 5 function button controls > Ability to program a networked Smart Multi-loop control panel from the front screen > Accommodates wiring lengths up to 1000m from the control panel > Network can be wired in either a bus or a ring topology if a redundant path is required > 8 password protected access accounts available (1 admin level, 7 user level) > Interface allows alarms, tech alarms and fault events to be easily viewed > Low power consumption > Small enclosure |
| Brand | Zeta |
|---|---|
| Manufacturer Part No. | SMART/REP |
| Product Series | Zeta Addressable |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Zeta MKII |
| Colour | Black |
| Warranty | 2 Years |
FAQ’s for Zeta SmartConnect Multi-Loop Touchscreen Repeater Panel (SMART/REP)
Product Specification for Zeta SmartConnect Multi-Loop Touchscreen Repeater Panel (SMART/REP)
| Product code: |
SMART/REP |
| Description: | Zeta SmartConnect Touch Screen Repeater Panel |
| Dimensions: | W:340mm x H:230mm x D:96mm |
| ELECTRICAL | |
| Operational voltage: |
28 VDC |
| Quiescent current: |
78mA |
| Max. current: |
100mA |
| NETWORK | |
| Communication protocol: | RS485 |
| Max. network size: | 64 nodes |
| Max. distance between nodes: |
1KM (using a screened data cable) 100m (using a standard fireproof cable) |
| Network Wiring Typologies: | Bus Ring (recommended) |
| DISPLAY | |
| LCD: | 4.3” Resistive touch screen. 480 x 272 pixel resolution |
| LED indicators: | 2 Red (1 x Fire, 1 x Sounder Active), 1 Green (Power), 10 Yellow (1 x Relay Delay, 1 x Fault, 1 x Sounder Delay, 1 x Controls Active, 1 x General Disablement, 1 x General Test, 1 x Sounder Fault/Disablement, 1 x Sounder Delay 1 x System Fault, 1 x More Data) |
| Button controls: | Stop Sounders, Silence Buzzer, Scroll Display, Reset, Start Sounders |
| ENCLOSURE | |
| Cable entries: | 5 |
| Terminal wiring size: |
28-12 AWG |
| Material: | Zintec |
| Colour: | RAL9005 |
| Operating temperature: | -5 to +40oC |
| Max humidity: | 93% RH Non-Condensing |
| Weight: | 2.3kg |
