Zeta Infinity8 1 Zone Conventional Fire Alarm Panel (IN1)
SKU
IN1
£155.53 £129.61
Zeta Infinity8 1 Zone Conventional Fire Alarm Panel (IN1)
- Buy 10 for £150.74 £125.62 each and save 3%
Product Details for Zeta Infinity8 1 Zone Conventional Fire Alarm Panel (IN1)
The Zeta Infinity8 1 Zone Conventional Fire Control Panel (IN1) is housed in an attractive, flame-retardant ABS enclosure and uses a switch-mode power supply. The front cover is removable, allowing ease of access for cable installations. Space for up to 3Ah batteries. Meets all requirements of EN54 parts 2 & 4.
This panel can also be ordered with a metal back box that accommodates up to 7Ah batteries within the panel housing. (see product IN1/M)
Key Features of the IN1 |
|---|
| > Single zone > Access via password > One man test facility > Disablement facility for zones & sounders > Space for up to 3Ah batteries > Complies with EN54 parts 2 & 4 |
| Brand | Zeta |
|---|---|
| Manufacturer Part No. | IN1 |
| Product Range / Series | Zeta Conventional |
| Primary Power Source | Mains Powered (230V) |
| System Type | Conventional |
| Number of Zones | 1 |
| Colour | Grey |
| Warranty | 2 Years |
Write Your Own Review
FAQ’s for Zeta Infinity8 1 Zone Conventional Fire Alarm Panel (IN1)
No questions yet. Be the first to ask the question!
Product Specification for Zeta Infinity8 1 Zone Conventional Fire Alarm Panel (IN1)
| Product code: | IN1 |
| Description: | Zeta Infinity8 1 Zone Panel |
| Dimensions: | 371mm x 302mm x 93mm |
| Mains voltage: | 230V AC +10% / -15% @ 50/60 Hz |
| System voltage: | 24V DC (Nominal) |
| Zone voltage: | 21V DC (Nominal) |
| Sounder Alarm Output: | 2 x 150mA @ 24V DC |
| Fault Relay: | 1 x Volt Free Relay, SELV @ 1A Max |
| Zone capacity: | 32 devices per zone |
| Remote sounder operation: | Via N/O contact connected to Class Change |
| Sounder activation delay: | 0 to 10 minutes in 1 minute increments |
| Zone end of line: | 1N4002 Diode (Cathode stripe to zone +ve) |
| Sounder end of line: | 10K resistor |
| Charger voltage: | 27.6V |
| Battery cut off: | Battery voltage less than 20V |
| Battey internal resistance limit: | 0.9 ohm |
| Max. battery space: | 2 x 3.4 Ah, 12 Vdc sealed lead acid |
| Weight: | 3 kg (excluding batteries) |
