Electro Detectors Zerio Plus Intelligent Wired Antenna (EDA-Z6010)

For larger systems where the radio range of the control panel is not sufficient, it can be increased by adding wired antennas. The antenna is connected using a four-core twisted pair cable to the radio control or radio booster panel. Multiple units can be wired in parallel from a single panel. The wired antenna acts as a radio booster in terms of transmitting / receiving signals to/from devices, but communicates with the control panel via the cable.

The EDA-Z6010 is powered through the cable so no backup battery is required. Configuration could not be simpler as the wired antennas are added via the panel menus.

There is sufficient space inside the unit to allow easy cable termination using screw terminals. When connecting multiple units, terminals for RS485 in and RS485 out, are provided.

The SMA connector on the unit allows easy fitting of the supplied stub antenna which is locked in place by the enclosure or a weatherproof dipole antenna can be fitted.

Indicators on the unit provide information for the supply, fault and status.
