Vimpex Identifire Single Gang PSU 12/24V, Red, Surface (10-3010RSG-S)
SKU
10-3010RSG-S
£38.83
£32.36
Vimpex Identifire Single Gang PSU 12/24V, Red, Surface (10-3010RSG-S)
- Buy 10 for £38.23 £31.86 each and save 2%
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Vimpex Identifire Single Gang PSU 12/24V, Red, Surface (10-3010RSG-S)
The Vimpex Identifire Single Gang PSU (10-3010RSG-S) is a compact device configured in a standard Identifire single gang form. It is compatible with the Identifire range and is capable of supplying either 12 or 24 V dc. Used in combination with the Identifire range of relays, it is a perfect solution for powering door holders, sounders and visual indicators.
It fits the majority of recessed single gang boxes (flush or surface mounted) using an Identifire backbox.
Key Features of the 10-3010RSG-S |
|---|
|
> Works at 12 or 24 V dc selectable via link
> Red > Surface mounted > Green LED power indicator > PCB cover protects users from mains voltage |
| Brand | Vimpex |
|---|---|
| Manufacturer Part No. | 10-3010RSG-S |
Write Your Own Review
FAQ’s for Vimpex Identifire Single Gang PSU 12/24V, Red, Surface (10-3010RSG-S)
No questions yet. Be the first to ask the question!
Product Specification for Vimpex Identifire Single Gang PSU 12/24V, Red, Surface (10-3010RSG-S)
| Product: | Vimpex Identifire Single Gang PSU |
| Product code: | 10-3010RSG-S |
| Dimensions: | W:89mm x H:100mm x D:35mm |
| Output voltage: | 12/24 V DC |
| Output current (dc): | 800 / 400 mA |
| Input voltage (ac): | 110 - 250V |
| Typical efficiency: | 85% |
| Status LED: | Green (PSU operating) |
| Output rating: | Continuous |
| Load rating (Ω) resistive: | 15/60 |
| Operating temperature: | -20 to +50 °C |
| Mounting method: | Surface |
| Colour: | Red |
