Vimpex Hydrosense ID Addressable Interface Module (2 Zones) (ID-WLDM)
SKU
ID-WLDM
£246.22
£205.18
Vimpex Hydrosense ID Addressable Interface Module (2 Zones) (ID-WLDM)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Vimpex Hydrosense ID Addressable Interface Module (2 Zones) (ID-WLDM)
The Vimpex Hydrosense ID Interface Module (ID-WLDM) has 2 outputs which can use for 2 zones of Hydrowire, 2 zones of Hydrosense ID Leak Detection Probe probes or 1 zone of each. Each Sub address can be uniquely identified.
Key Features of the ID-WLDM |
|---|
|
> 1 Address for 2 Outputs
> Each sub address can be uniquely identified > Use for 2 zones of Hydrowire, 2 zones of Hydrosense ID Leak Detection Probe probes or 1 zone of each. > Up to 508 probes per system, 25,400 m of cable or a combination of both |
| Brand | Vimpex |
|---|---|
| Manufacturer Part No. | ID-WLDM |
Write Your Own Review
FAQ’s for Vimpex Hydrosense ID Addressable Interface Module (2 Zones) (ID-WLDM)
No questions yet. Be the first to ask the question!
Product Specification for Vimpex Hydrosense ID Addressable Interface Module (2 Zones) (ID-WLDM)
| Product: | Vimpex Hydrosense ID Interface Module - 2 Zones |
| Catalogue no.: | ID-WLDM |
| Dimensions: | W:115mm x L:160mm x D:45mm |
| CURRENT CONSUMPTION (ESP) | |
| Quiescent @ 41V: | 382uA |
| LEDs: | Alarm: 3mA per LED Fault: 3mA per LED |
| SCI Active: | 3.5mA |
| Polling: | 22mA |
| SUPPLY VOLTAGE (ESP) | |
| Loop voltage (low): | 17 - 32V dc |
| Loop pulse voltage: | 7 - 9V dc |
| DETECTION CIRCUIT CHARACTERISTICS | |
| Short circuit: | <400Ω |
| Active nominal sensitivity: | ≈37Ω |
| Active low sensitivity: | ≈18Ω |
| Max. length of Hydrowire: | 50m per circuit |
| EOL device: | EOL Device: ID-WLDM-EOL |
| Max. humidity: | 95% (non-condensing) |
| Weight: | 220g |
