Vimpex Hydrosense ID Addressable Mains Relay Controller (ID-WLMRC)
SKU
ID-WLMRC
£153.90
£128.25
Vimpex Hydrosense ID Addressable Mains Relay Controller (ID-WLMRC)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Vimpex Hydrosense ID Addressable Mains Relay Controller (ID-WLMRC)
The Vimpex Hydrosense ID Addressable Mains Relay Controller (ID-WLMRC) is capable of switching a 250 Vac 5 A load, and is ideal for controlling solenoid valves or plant equipment.
The ID-WLMRC is a loop driven addressable device, and can be integrated into a Cause and Effect matrix using the Loop Explorer Software. The addressable element also allows the user to allocate the device with a location-specific name.
Key Features of the ID-WLMRC |
|---|
|
> Addressable interface enabling 110/230V 5A switching of solenoids and other electro-mechanical devices
> Fully configurable via cause and effects > Provides several monitored inputs/outputs > Loop powered |
| Brand | Vimpex |
|---|---|
| Manufacturer Part No. | ID-WLMRC |
Write Your Own Review
FAQ’s for Vimpex Hydrosense ID Addressable Mains Relay Controller (ID-WLMRC)
No questions yet. Be the first to ask the question!
Product Specification for Vimpex Hydrosense ID Addressable Mains Relay Controller (ID-WLMRC)
| Product: | Vimpex Hydrosense ID Addressable Mains Relay Controller |
| Catalogue no.: | ID-WLMRC |
| Dimensions: | L:157mm x H:127mm x D:35mm |
| Operating voltage: | 17 - 41V dc |
| Current consumption: | 33mA (when polling) |
| Relay contact rating: | 48Vdc, max. 2A or 250 Vac, Max 5A |
| Input EOL rating: | 10,000 Ohms, 0.25W |
| Operating temperature: | -10 to +50oC |
| Storage temperature: | -30 to +60oC |
| Max. humidity: | 95% (non-condensing) @ 40oC |
| Weight: | 325g |
