Vimpex Conventional Sycall Blue Call Point - Surface Mounted
SKU
SY-BS01
£17.62
£14.68
Vimpex Conventional Sycall Blue Call Point – Surface Mounted (SY-BS01)
- Buy 10 for £17.34 £14.45 each and save 2%
Available on Backorder
This item is not currently in stock, but it is available to backorder. Contact us for lead time.
Product Details for Vimpex Conventional Sycall Blue Call Point - Surface Mounted
Vimpex Conventional Sycall Blue Call Point – Surface Mounted (SY-BS01)
Key Features of the SY-BS01 |
|---|
|
> Blue, Series 01
> Surface mount > Clean contact or choice of 470 Ωr 680 Ω series resistors in the same model > Aesthetically appealing design > Resettable Element > Optional highly visible LED > Light ring when activated > Luminescent element visible for up to 8 minutes |
| Brand | Vimpex |
|---|---|
| Manufacturer Part No. | SY-BS01 |
Write Your Own Review
FAQ’s for Vimpex Conventional Sycall Blue Call Point - Surface Mounted
No questions yet. Be the first to ask the question!
Product Specification for Vimpex Conventional Sycall Blue Call Point - Surface Mounted
| Product: | Vimpex Sycall Conventional Blue Call Point, surface mount |
| Catalogue no.: | SY-BS01 |
| Dimensions: | W:88mm x H:87mm x D:30mm |
| Maximum voltage: | 30V dc |
| Minimum voltage: (LED may be low output or not operate below min. voltage) | 4.5V dc if LED with R1 is chosen 6.0V if LED with R2 is chosen |
| Current rating (non activated): | 0 mA |
| Current rating (activated): | 18 mA @ 12V dc - R1 13 mA @ 12V dc - R2 45 mA @ 24V dc - R1 31 mA @ 24V dc - R2 |
| Cable termination: | 0.5 - 2.5mm2 |
| Operating temperature: | -30oC to +70oC |
| IP rating: | IP42 |
| Material: | ABS/Polycarbonate/PA6+glass fibre |
| Operating humidity: | 95% non-condensing |
| Colour: | Blue |
| Weight: | 0.180 kg |
