Global Fire OCTO+ Panel Internal Printer Assembly (OCTO-PRINTER)
SKU
OCTO-PRINTER
£287.66
£239.72
Global Fire OCTO+ Panel Internal Printer Assembly (OCTO-PRINTER)
Available on Backorder
This item is not currently in stock, but it is available to backorder. Contact us for lead time.
Product Details for Global Fire OCTO+ Panel Internal Printer Assembly (OCTO-PRINTER)
The Global Fire OCTO+ Printer Assembly (CHAMELEON INTERNAL PRINTER) has a 40 column internally mounted thermal printer to provide a hardcopy of the OCTO+ panel log containing all relevant events occurring in the system.
All events are date and time stamped and are backed by a 10000 events deep rolling log kept in the panel’s non-volatile memory.
Key Features of the OCTO-PRINTER |
|---|
|
> 40 column internally mounted thermal printer
> provides hard copy of OCTO+ panel log of events > Events are date and time stamped > Backed by a 10,000 events rolling log > Requires connection to one of the BMS channels in the panel via 5-way flat cable > Refer to panel's installation manual for details |
| Brand | Global Fire Equipment |
|---|---|
| Manufacturer Part No. | OCTO-PRINTER |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | GFE ZEOS |
| Warranty | 10 Years |
Write Your Own Review
FAQ’s for Global Fire OCTO+ Panel Internal Printer Assembly (OCTO-PRINTER)
No questions yet. Be the first to ask the question!
Product Specification for Global Fire OCTO+ Panel Internal Printer Assembly (OCTO-PRINTER)
| Dimensions: | W:194mm x L:256mm x H:75mm |
| Supply voltage: | 20 to 30V DC |
| Supply current: |
Standby: 43mA max / printing 500mA max |
| Panel channel connection: |
OCTO+CH1, CH2 or CH3; GEKKO CH1 or CH2 |
| Connectons: | 5-way molex (flat cable provided) |
| Paper: | 57.5+/-0.5mm with max diameter 36mm (approx 12 metres) |
| Max cable size: | 2.5mm |
| Operating/storage temp: |
0oC to +50oC |
| Humidity: | 95% RH Non-condensing |
| Compatibility: | Windows XP/7/8/10, MacOS, Linux, Android, IOS |
| Compatible panels: | All CHAMELEON Panels (G-One, GEKKO, OCTO+, NODE+) |
| Weight: | 633g |
