Nittan Evolution Conventional Dual Band IR Flame Detector (EVC-IR)
SKU
EVC-IR
£572.40
£477.00
Nittan Conventional Dual Band IR Flame Detector (EVC-IR)
In Stock
Product Details for Nittan Evolution Conventional Dual Band IR Flame Detector (EVC-IR)
The EVC-IR uses both Dual Wavelength and flicker frequency sensing techniques for maximum false alarm reduction and sensitivity to real flaming fires.
Base Sold Separately
Key Features of the EVC-IR |
|---|
|
> Dual Band IR Flame Detector
> Omniview 360° LED > Internal Alarm Current Limiting Resistor > Wide Operational Voltage Range (12v-32v) |
| Brand | Nittan |
|---|---|
| Manufacturer Part No. | EVC-IR |
| Primary Power Source | 24V DC |
| System Type | Conventional |
| Sensor Type | Infrared (IR) |
| Detectable Medium | Flame |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Nittan Evolution Conventional Dual Band IR Flame Detector (EVC-IR)
No questions yet. Be the first to ask the question!
Product Specification for Nittan Evolution Conventional Dual Band IR Flame Detector (EVC-IR)
| Manufacturer: | Nittan |
| Product Code: | EVC-IR Zero OHM |
| Sensor Method: | CO2 Resonant Emission, Flickering, Dual Wavelength |
| Sensor Element: | 2 x Infrared Wavelength sensors |
| Sensor Class: | Class 1(25m), Class 2(17m), Class 3 (12m) |
| Operating Voltage: | 10V d.c to 32V d.c |
| System Voltage: | 24V d.c |
| Quiescent Current: | 100µA |
| Alarm Current: | 50mA @ 24V |
| Current for external remote LED indicator: | 2mA |
| Sensor Viewing Angle: | 100° Max (±50°) |
| Operating Temperature: | – 25°C to + 70°C |
| Storage Temperature: | – 25°C to + 70°C |
| Charging Time: | 30 Seconds |
| Relative Humidity: | ≤ RH95% non-condensing |
| I.P. Protection Rating: | IP42 / IP52 - TBD by Marine tests |
| Material: | ABS/PC alloy |
| Dimensions: | ∅104mm x 29mm (Sensor head) - ∅104mm x 45mm (Sensor head and UB-4) |
| Mass: | 127g (Sensor head) - 186g (Sensor head and UB Series base) |
| Approval Conformance: | EN54-10:2002/A1:2005 |
| CE Certificate number: | 0832-CPD-XXXX |
