Lumi-Plugin 3000K IP20 Fire Rated LED Downlight with Emergency Light - Corridor (Warm White) (LP110WH3KCOEM)
- Buy 10 for £122.06 £101.72 each and save 2%
- Buy 20 for £120.16 £100.13 each and save 3%
- Buy 30 for £118.25 £98.54 each and save 5%
Product Details for Lumi-Plugin 3000K IP20 Fire Rated LED Downlight with Emergency Light - Corridor (Warm White) (LP110WH3KCOEM)
The Lumi-Emergency Corridor is a standard 3000k Lumi-Plugin LED downlight with integrated emergency lighting. In an emergency it activates to ensure that all exit routes are well lit for 3 hours.
Far-reaching, horizontal beam angle provides emergency lighting for the length of corridors, hallways and exit routes.
Lumi-Emergency Corridor has a 6500k, 232 lm light with a 155 x 115 degrees beam angle. It is non-maintained and mains powered with a battery backup.
The Downlight emits 600 Lumens and has a 3000k warm white LED bulb which is dimmable and easily replaceable.
Every detail of the Lumi-Plugin Downlight has been designed, tested and engineered for seamless integration, effortless installation and flawless protection.
Installation of the fitting is made easy. With a driver already fitted on the inside, you only need to connect the junction box on the outside.
Tried, tested and Fire Rated 30/60/90. The Lumi-Plugin Downlight exceeds the strictest of fire safety regulations.
Simply remove the central cap and all of the compatible space-saving, cost-saving and life-saving plugins can slot into place.
Key Features of the LP110WH3KCOEM |
|---|
|
> Mains powered
> Battery back-up > Non maintained > 3 hour emergency light feature > Horizontal beam angle optimal for lighting the length of corridors/hallways in emergency situation > Emergency 6500k lighting, 232lm, 155 x 115 degree beam angle light > Non emergency 600 lm, 4000k white > Fire-rated 30/60/90 > IP20 rated > 5 year manufacturer warranty |
| Brand | Lumi-Plugin |
|---|---|
| Manufacturer Part No. | LP110WH3KCOEM |
FAQ’s for Lumi-Plugin 3000K IP20 Fire Rated LED Downlight with Emergency Light - Corridor (Warm White) (LP110WH3KCOEM)
Product Specification for Lumi-Plugin 3000K IP20 Fire Rated LED Downlight with Emergency Light - Corridor (Warm White) (LP110WH3KCOEM)
Lumi-Emergency Corridor Specification
| Battery size / type: | 3.2V 3.8Ah LiFePO4 |
| Beam angle: | 155 degrees |
| Voltage: | 240V |
| Light source: | Samsung LH315B |
| Colour temperature: |
6500K |
| Non-maintained: | Yes |
| Output at 550mA: |
232 lumens |
| Power rating: |
3W |
| Wiring method: |
Series connection via C4201 plug |
| Colour: | White |
| Dimensions: | Cut-out size: 92mm; Height 72.3mm; Diameter 110mm; Depth 55mm (see datasheet for diagram) |
Lumi-Plugin Downlight
| Lumens: | 600 |
| Product Code: | LP110WH3KCOEM |
| Wattage: | 8.2W |
| Voltage: | 220-240V AC 50Hz |
| Product Weight: | 0.5kg |
| Dimmable: | Trailing Edge |
| Fire rated: | 30/60/90 - Solid Joist 30 - Webbed Joist & I-Joist |
| Built in driver: | Yes |
| Colour temperature: | 3000K Warm White |
| Cut out size: | 92mm |
| Warranty/hours: | 5 years / 50,000 hours |
| Colour rendering index (CRI): | >80 |
| Beam Angle: | 100 degrees |
| Product depth/diameter: | 55mm/110mm |
| kWh per 1000hr life: | 10 kWh |
| Luminaire efficacy: | 86.05 lm/w |
| Energy rating: | F |
| Product colour: | White |
