Kidde RBUN 230V Trigger Input and Relay Module
SKU
RBUN
£25.36 £21.13
Kidde RBUN 230V Trigger Input and Relay Module
- Buy 10 for £24.96 £20.80 each and save 2%
- Buy 20 for £24.58 £20.48 each and save 3%
- Buy 50 for £24.18 £20.15 each and save 5%
The Kidde RBUN is a 230v AC mains-powered, surface mounting relay module with 9v alkaline battery back-up.
Triggering this device will cause interlinked smoke, heat or carbon monoxide alarms to sound and the relay to activate when an interconnected sprinkler system is activated. The RBUN can also be used as an interface with other auxiliary devices with a normally-open (N/O) contact, such as manual call points.
Relay with volt-free contacts
Smoke / Heat Alarms
The relay in the RBUN activates when interlinked smoke / heat alarms sound an alarm. The installer must pre-select the Selector switch to 'SMOKE'
Carbon Monoxide Alarms
The relay will activate when the interconnected carbon monoxide alarms sound an alarm. The installer must pre-select the Selector switch on the RBUN relay module to 'CO'.
| Key Features |
|---|
| > Enables interlinked smoke, heat and CO alarms to sound when a connected sprinkler system is activated > Can be used as an interface with other auxiliary devices with a N/O contact e.g. manual call points > 230V AC mains powered with 9v alkaline battery back-up > Suitable for surface mounting > 5 year manufacturer's warranty |
| Manufacturer | Kidde |
|---|---|
| MPN | RBUN |
| EAN | 0047871281527 |
Write Your Own Review
Sort By:
No questions yet. Be the first to ask the question!
| Supply Voltage: | 230V AC 50Hz, 50mA Max |
| Battery Back-up: | Alkaline 9V |
| Battery Life: | 1-year |
| Output Relay Contacts: | Contact ratings: 230V AC @ 3Amps; 24V DC @ 3Amps |
| Sprinkler Interconnect: | 9V DC output with return for connection to auxiliary NO volt-free contact |
| Temperature Range: | 0°C to 40°C |
| Humidity Range: | 0% to 90% RH, non-condensing |
| Dimensions: | Diameter 133.5mm x Depth 31.5mm |
| Weight: | 222g |
| Warranty: | 5-year |
| Unit Pack Dimensions: | 33 x 136 x 136mm |
| Unit Pack Weight: | 270g |
