Kentec Syncro XT+ Extinguishing Control Panel - 1 Loop, 1 Area (Apollo Protocol)
SKU
A31161M3
£1,266.88 £1,055.73
Kentec Syncro XT+ Extinguishing Control Panel - 1 Loop, 1 Area (Apollo Protocol)
The Kentec Syncro XT+ Extinguishant Control Panel - 1 loop, 1 area Apollo protocol (A31161M3) benefits from the sophisticated detection techniques provided by addressable fire detectors. It has up to 16 zones of addressable detection so each detector is able to contribute to the extinguishant release.
It also includes other benefits of analogue addressable systems such as control of loop connected sounders, beacons and input/output modules.
With up to 16 zones of addressable detection over one or two loops it ensures every detector can contribute to the extinguishant release.
The Syncro XT+ has up to four extinguishing areas and two releasing outputs per area which can be controlled via simple coincidence detection or via more complex cause and effects configured by the Loop Explorer configuration programme.
Each extinguishant area has a comprehensive set of inputs and outputs and is configurable via the Loop Explorer configuration programme.
All extinguishant areas may have up to seven serially connected Sigma Si status indication and control units, or ancillary relay boards connected via a simple four-core cable.
With the addition of a Syncro network card, Syncro XT+ control panels can be networked to provide scalable extinguishing systems for all sizes of installation.
| Key Features |
|---|
| > Syncro XT+ 1 loop - Apollo protocol > 1 single area extinguishing control module > Addressable control panel > Up to 16 zones of addressable detection over one loop > Detection & extinguishing controls and status indicators > Dual action manual extinguishing release control > Auto/manual keyswitch > Integral 3 Amp power supply 230V AC input > Space for 2 x 12V 12Ah SLA batteries > Surface Mount M3 enclosure W: 385mm x H:520mm x D:110mm > Two releasing outputs per area > 1st & 2nd stage sounder outputs for each area > 1st & 2nd stage volt free changeover contacts for each area > Released volt free contact per area > Fault volt free contact per area > Programmable extinguishant delay and output duration > Countdown indicator shows time until release > Monitored remove hold input/mode select (door interlock) input > Monitored remote released pressure switch input > Monitored Abort input > Serial connections for Sigma Si status units & ancillary boards > EN12094-1, EN54-2 & EN54-4 approved |
| Manufacturer | Kentec Electronics |
|---|---|
| MPN | A31161M3 |
Write Your Own Review
Sort By:
No questions yet. Be the first to ask the question!
| Product Code: | A31161M3 |
| Product Dimensions: | W:385mm x H:520mm x D:110mm |
| Construction: | 1.2mm mild sheet steel surface mount enclosure |
| IP Rating: | IP30 |
| Finish: | Epoxy powder coated |
| Colour: | lid & box BS 00 A 05 grey - fine texture control panel & labels RAL 7047 light grey - satin |
| Weight: | 10kg |
| Mains supply: | 230V AC +10-15% (100W max) |
| Mains supply fuse: | 1.6A (FL.6A L250V) |
| Power supply rating: | 3A inc battery charge 28V+/-2V |
| Maximum ripple current: | 200 millivolts |
| Battery charge voltage: | 27.6V DC nominal (temperature compensated) |
| Battery charge current: | 0.7A maximum |
| Battery fuse: | 20mm, 3.15A glass |
| Current draw in mains fail condition: | 54 mA per module |
| Max. current draw from batteries: | 3A |
| Sigma XT+ module Aux 24V output: | Fused at 500mA with electronic fuse - 1 per extinguishant area |
| Syncro AS Aux 24V output: | Fused at 2.5A - not available to user |
| 1st & 2nd stage sounder outputs: | 21 to 28V DC Fused at 1A with electronic fuse |
| Fault relay contact rating: | 5 to 30VDC 1A maximum for each |
| Fire relay contact rating: | 5 to 30V DC 1A maximum for each |
| Local fire relay contact rating: | 5 to 30V DC 1A maximum for each |
| First stage contact rating: | 5 to 30V DC 1A maximum for each |
| Second stage contact rating: | 5 to 30V DC 1A maximum for each |
| Extract contact rating: | 5 to 30VDC 1A maximum for each |
| Zone quiescent current: | 2mA maximum |
| Terminal capacity: | 0.5mm2 to 2.5mm2 solid or stranded wire |
| No. of sounders per circuit: | Dependent on type and current consumption - typically 20+ |
| Monitored input end of line: | 6K8 5% ½ W resistor |
| Sounder circuit end of line: | 10K 5% ¼ W resistor |
| Extinguishant output end of line: | 1N4004 Diode |
| No. of detection circuits: | 1 |
| No. of sounder circuits: | Dependent on model 21 to 28V DC |
| Extinguishant releaseoutput: | 1 to 28V DC. Fused at 1A |
| Extinguishant release delay: | Adjustable 0 to 60 seconds (+/- 10%) |
| Extinguishant release duration: | Adjustable 60 to 300 seconds |
| SIL, AL, FLT, RST inputs: | Switched -ve, min resistance 0 Ohms, max resistance 100 Ohms |
| Cabling: | FP200 or equivalent (max capacitance 1uF max inductance 1mH) |
| Monitored inputs normal threshold (allowable EOL): | 10K ohm to 2K ohm |
| Monitored inputs alarm threshold: | 2K ohms to 150 ohms +/- 5% |
| Monitored inputs short circuit threshold: | 140 ohms to 0 ohms +/- 5% |
| Status unit/ancillary board connection: | Two wire RS485 connection (EIA 485 specification) |
| Status unit power output: | 21 to 28V DC. Fused at 500mA with electronic fuse |
