Kentec Sigma ZSi - 6 LED Weatherproof Extinguishant Status Unit (W921000W8)
SKU
W921000W8
£147.35
£122.79
Kentec W921000W8 Sigma ZSi - 6 LED Weatherproof Extinguishant Status Unit
Out of Stock
This item is currently out of stock and is not available to order
Product Details for Kentec Sigma ZSi - 6 LED Weatherproof Extinguishant Status Unit (W921000W8)
The Kentec W921000W8 Sigma ZSi - 6 LED Weatherproof Extinguishant Status Unit extends the indications as well as some controls of the Sigma ZXT Extinguishant Control Panel to other locations within the fire protection system. They can be introduced to make operation of the system more practical, within areas that have multiple access points (or doors).
A maximum of 7 status units may be connected to each control panel extinguishant area.
All units connect to a two-wire data communications bus and are powered by the Auxiliary 24V DC output of compatible, extinguishant Control Panels.
Key Features of the W921000W8 |
|---|
|
> Sigma ZSi - 6 LED Extinguishant Status Unit
> Weatherproof > Extinguishing release countdown display > RS485 connection to extinguishing panel > Maximum 7 units per panel > Supply voltage 21 - 30V DC > Serial connection - max 7 Si per extinguishing area > Status LEDs - Status LEDs - Manual Only, Auto/Manual, Hold Operated, Disabled, Imminent & released > 7 Segment LED display > Auto/Manual doorlock input > Remote Hold input > Max current draw 0.07A > Surface mount IP65 S8 enclosure > W:256mm x H:170mm x D:60mm > Compliant with EN12094-1 |
| Brand | Kentec Electronics |
|---|---|
| Manufacturer Part No. | W921000W8 |
Write Your Own Review
FAQ’s for Kentec Sigma ZSi - 6 LED Weatherproof Extinguishant Status Unit (W921000W8)
No questions yet. Be the first to ask the question!
Product Specification for Kentec Sigma ZSi - 6 LED Weatherproof Extinguishant Status Unit (W921000W8)
| Product Code: | W921000W8 |
| Description: | 6 lamp status unit |
| Product Dimensions: | W:256mm x H:170mm x D:60mm Surface mount, IP65 S8 enclosure |
| Construction: | 1.2mm mild sheet steel |
| IP Rating: | IP65 |
| Finish: | Epoxy powder coated |
| Colour: | lid & box BS 00 A 05 grey - fine texture |
| Weight: |
1kg |
| Power supply: | 21 - 30V DC |
| Max. current draw: |
70mA |
| Quiescent consumption: | 33mA |
| Max. no. of status units: | 7 |
| Max. no. of ancillary boards: | 8 |
| Monitored inputs EOL resistor: | 6K8 0.5W Resistor fitted to terminals |
| Monitored inputs normal threshold: | 8K ohm to 1K ohm |
| Monitored inputs trigger threshold: | 700 ohms to 100 ohms |
| Monitored inputs short circuit threshold: |
99 ohms to 0 ohms |
| Data connection: |
2-wire RS485 connection (max 1200m) |
