Kentec Sigma CP-R 2 Zone Repeater Panel - 230v (K01020M2)
SKU
K01020M2
£254.98
£212.48
Kentec Sigma CP-R 2 Zone Repeater Panel - 230v (K01020M2)
Limited Stock
Only 2 left
Product Details for Kentec Sigma CP-R 2 Zone Repeater Panel - 230v (K01020M2)
The Kentec Sigma CP-R K01020M2 is a 2 zone repeater fire panel that is compatible with all Kentec Sigma CP control panels which have operating software version V2.0 or above.
This repeater panel is 230v AC powered and comes with an integral 1.6A PSU so it only requires a two core data cable from the main control panel for communication on the system.
A mixture of repeaters, ancillary boards or sounder boards up to a maximum of 7 of each type can be connected to a control panel and each is allocated an address from 1 to 7 using a binary coded DIL switch. The total length of the data cable from the main panel to the last repeater panel must not exceed 1200 metres.
Key Features of the K01020M2 |
|---|
|
> Two-wire serial connection
> Up to 7 panels per system > 230v AC powered with integral 1.6A PSU > Full control over main panel > Volt free fire and fault contact outputs |
| Brand | Kentec Electronics |
|---|---|
| Manufacturer Part No. | K01020M2 |
Write Your Own Review
FAQ’s for Kentec Sigma CP-R 2 Zone Repeater Panel - 230v (K01020M2)
No questions yet. Be the first to ask the question!
Product Specification for Kentec Sigma CP-R 2 Zone Repeater Panel - 230v (K01020M2)
| Construction | 1.2mm mild sheet steel |
| IP Rating | IP30 |
| Finish | Epoxy powder coated |
| Colour - lid & box | BS 00 A 05 grey - fine texture |
| Colour - control panel & labels | RAL 7047 light grey - satin |
| Dimensions | 385mm x 310mm x 60mm |
| Weight | 6kg |
| Supply Voltage (K models) | 230V AC (+10%/-15%) |
| Mains Supply Fuse | 1.6A 250V |
| Power Supply DC rating | 24V 1 Amp |
| Maximum battery size | 7aH 12V (2 per panel) |
| Fault contact rating | 30V DC 1 Amp |
| Fire contact rating | 30V DC 1 Amp |
| Cable capacity | 2.5mm² per terminal |
| Operating temperature | -5°C to +40°C |
| Operating humidity | <95% (non condensing) |
