Hyfire Conventional Sounder Beacon - Red, EN54-23 (HFC-SBR-23-03)
SKU
HFC-SBR-23-03
£66.05
£55.04
HFC-SBR-23-03 Hyfire Conventional Sounder Beacon - Red, EN54-23
- Buy 10 for £63.00 £52.50 each and save 5%
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Hyfire Conventional Sounder Beacon - Red, EN54-23 (HFC-SBR-23-03)
The Hyfire HFC-SBR-23-03 is a red, Conventional Wall Sounder VAD that can be used as a standalone conventional device or an intelligent unit by the addition of a wired or wireless module. Weatherproof.
Key Features of the HFC-SBR-23-03 |
|---|
|
> Flexible modular design
> 5 year product warranty > 3rd party approval to EN54-3 (Type B) and EN54-23 > 32 Tone Settings > Two stage alarm capability > Weatherproof > Easy to install > Silent sounders setting for beacon only use > Microphone self test facility > Robust & high reliability |
| Brand | Hyfire |
|---|---|
| Manufacturer Part No. | HFC-SBR-23-03 |
Write Your Own Review
FAQ’s for Hyfire Conventional Sounder Beacon - Red, EN54-23 (HFC-SBR-23-03)
No questions yet. Be the first to ask the question!
Product Specification for Hyfire Conventional Sounder Beacon - Red, EN54-23 (HFC-SBR-23-03)
| Product: | Hyfire Conventional Sounder Beacon - Red, EN54-23 |
| Product code: | HFC-SBR-23-03 |
| Dimensions: |
see attached datasheet for diagram |
| Power supply voltage range: |
15Vdc - 40Vdc |
| Activated current load (High vol) |
11-25 mA @ 24Vdc |
| Acoustic frequency range: | 400 - 2900 Hz |
| Max. acoustic output: | 100 dB(A) @1m |
| Operating temperature: | -10oC to +55oC (no icing) |
| Max humidity (non condensing): | 95% RH |
| Ingress protection: |
IP65 |
| Weight: | 290g (inc. back box) |
