Hochiki YBN-R/3(SCI) Short Circuit Isolator Base - Ivory
SKU
YBN-R/3(SCI)
£14.77 £12.31
Hochiki YBN-R/3(SCI) Short Circuit Isolator Base - Ivory
Product Details for Hochiki YBN-R/3(SCI) Short Circuit Isolator Base - Ivory
The Hochiki YBN-R/3(SCI) is a sensor mounting base featuring an integral short-circuit isolator which will detect and isolate short-circuits on the loop. When a short-circuit is detected during power up the unit will drop the power to the rest of the loop
The YBN-R/3(SCI) is compatible with the ESP range of sensors and does not require a loop address. A remote fire LED facility is provided when a sensor is attached to the base
NOTE: A fitted sensor will still be powered when this device is isolating
Key Features of the YBN-R/3(SCI) |
|---|
| > Features integral short circuit isolator > Easy to fit > Slim profile > Matches standard base colours |
| Brand | Hochiki |
|---|---|
| Manufacturer Part No. | YBN-R/3(SCI) |
| Product Series | Hochiki ESP |
| Colour | Ivory |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Hochiki ESP |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Hochiki YBN-R/3(SCI) Short Circuit Isolator Base - Ivory
No questions yet. Be the first to ask the question!
Product Specification for Hochiki YBN-R/3(SCI) Short Circuit Isolator Base - Ivory
| Description | Hochiki Short Circuit Isolator Base |
| Product Code | YBN-R/3(SCI) |
| Dimensions: | Dia:100mm x H:13.7mm |
| Operating Voltage: | 17 - 41 V dc (24 V dc nominal) |
| Standby current: | 60 μA |
| Current drawn by isolator during fault condition: | < 4 mA |
| Maximum current consumption from remote LED: | 10 mA (limited by attached sensor) |
| Maximum continuous current: | 1 A |
| Maximum quantity per loop: | 127*1 |
| Ambient temperature range: | -10 °C to + 50 °C |
| Relative humidity: | 10% to 95% RH (at 40°C) |
| Colour/Case material: | Ivory / ABS |
| Base fixing centres: | 48 - 74 mm |
| Max. wire thickness: | 2.5mm2 / terminal |
| Weight: | 79g |
| *1 Check with Fire alarm control panel manufacturer for maximum loop quantities See AP0127 for short-circuit isolator specifications | |
