Hochiki Isolated Barrier (KFD0-CS-EX2.51P)
SKU
KFD0-CS-EX2.51P
£263.60
£219.67
Hochiki Isolated Barrier (KFD0-CS-EX2.51P)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Hochiki Isolated Barrier (KFD0-CS-EX2.51P)
The Hochiki KFD0-CS-EX2.51P is an isolated barrier that is used for intrinsic safety applications. It transfers DC signals from fire alarms, smoke alarms, and temperature sensors in hazardous areas. It can also be used to control I/P converters, power solenoids, LEDs, and audible alarms.
Reverse polarity protection prevents damage to the isolator caused by faulty wiring.
Since this isolator is loop-powered, use the technical data to verify that proper voltage is available to the field devices.
Key Features of the KFD0-CS-EX2.51P |
|---|
|
> 2-channel isolated barrier
> 24 V DC supply (loop powered) > Current input/output 0 mA ± 40 mA > I/P or transmitter power supply > Accuracy 1% > Reverse polarity protection > Up to SIL2 acc. to IEC 61508 |
| Brand | Hochiki |
|---|---|
| Manufacturer Part No. | KFD0-CS-EX2.51P |
| Product Series | Hochiki Intrinsically Safe |
| Primary Power Source | 24V DC |
| System Type | Conventional |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Hochiki Isolated Barrier (KFD0-CS-EX2.51P)
No questions yet. Be the first to ask the question!
Product Specification for Hochiki Isolated Barrier (KFD0-CS-EX2.51P)
| Description | Hochiki Isolated Barrier |
| Product Code | KFD0-CS-EX2.51P |
| Dimensions: | W:107mm x H:115mm x D:20mm |
| Maximum short-circuit current (Intrinsically Safe): | At Uin > 24 V: ≤ 65 mA |
| Number of channels: | 2 |
| Current Range (Not Intrinsically Safe): | 0 to 40 mA, nominal |
| Rise Time: | ≤ 5 ms at bounce from 4 ... 20 mA and Uin < 24 V |
| Max. Output Voltage in hazardous area: | for 4 V < Uin < 24 V: ≥ Uin - (0.37 x current in mA) - 1.0 for Uin > 24 V: ≥ 21 V - (0.36 x current in mA) |
| Transfer Accuracy at 20oC: | ≤ 200 μA |
| Loop Supply Voltage: | 4 to 35 V dc |
| Operating Temperature: | -20 °C to + 60 °C (continuous working) |
| Storage Temperature: | -40 °C to + 80 °C |
| Maximum Humidity: | 95% RH - Non Condensing (at 40 °C) |
| Mounting Methods: | DX070, SMB-2 or SMB-3 Enclosures |
| Weight: | 100g |
