Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
SKU
CSB-E(WHT)
£26.42
£22.02
Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
In Stock
Product Details for Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
The Hochiki CSB-E(WHT) is platform type sounder, which will accept the CDX Range of detectors mounted with an appropriate base. The improved electronics result in a very low current consumption with a high sound output.
A set of DIL switches are used to select the unit's tone and sound output (three settings, LOW, MEDIUM and HIGH).
Key Features of the CSB-E(WHT) |
|---|
|
> Robust design
> Low current consumption > Easy to install > Maximum 93 dB(A) 1 metre (Tone 1) > 32 user-selectable tones and 3 user-selectable volumes > Lockable cap available > EN54 Part 3 approval > Requires detector mounting base if fixing detector (YBN-R/6(WHT)) |
| Brand | Hochiki |
|---|---|
| Manufacturer Part No. | CSB-E(WHT) |
| Product Series | Hochiki CDX |
| Primary Power Source | 24V DC |
| System Type | Conventional |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
No questions yet. Be the first to ask the question!
Product Specification for Hochiki CSB-E(WHT) Conventional Sounder Base - White Case
| Description | Hochiki Conventional Sounder Base |
| Product Code | CSB-E(WHT) |
| Dimensions (mm): | Dia: 116 x H 25 |
| Sound output @1m, Tone 1: | Low: 86.2 dB(A) Medium: 87.7 dB(A) High: 91.2 dB(A) |
| Current consumption @ 24Vdc: | Low: 5.7 mA Medium: 7 mA High: 9.4 mA |
| Voltage range: | 18 – 30 V dc |
| No. of tones: | 32 |
| Operating frequency: | 440 Hz – 2900 Hz |
| IP rating: | IP21C |
| Operating temperature: | -20oC to +70oC |
| Compatible CDX Detectors: | SLR-E3N, DCD-AE3, DCD-CE3, DFJ-AE3, DFJ-CE3 |
| Compatible CDX Bases*: | YBN-R/6, YBO-R/6PA, YBO-R/6R, YBO-R/6RN, YBO-R/6RS, YBN-R/6SK |
| Colour: | White |
| Approval: | Approved to EN54 part 3 by the LPCB and VdS on tones 1, 3, 11, 25 and 27 |
| Weight: | 110g |
