The GSTDC-9503E is a stand alone loop isolator for overload and short circuit protection of GST DI-9000E series addressable fire panel loops. A partial or full short circuit condition on an addressable fire detection loop will adversely affect the functionality of multiple or even all devices connected to that loop. The DC-9503E short circuit isolator prevents complete loop failure by isolating the faulty loop section from the rest of the loop thus ensuring continued operation outside the affected section. Once the fault condition has been cleared, the DC-9503E automatically reconnects the affected section ensuring normal operation for the whole loop. A convenient LED indicator on the unit indicates the presence of an isolated condition, allowing the service engineer to quickly locate the affected loop section.
Key Features |
---|
> Protects against loop overload conditions due to partial of full short circuits > Automatically resets when condition is cleared > DIN-rail or surface mount > Local LED status indication > Ground fault detection support > EN54-17 certified and LPCB marked |
Manufacturer | GST |
---|---|
MPN | DC-9503E |
Write Your Own Review
Sort By:
No questions yet. Be the first to ask the question!
Code: | DC-9503E |
Description: | DI9000 Series intelligent loop isolator |
Dimensions: | W:45.3mm x H:78mm x D:28.5mm |
Status indication: | LED |
Compatibility: | GST DI-9000E systems |
Connectivity: | 2-wire loop |
Addressing method: | No addressing required |
Power supply type: | Loop powered |
Operating voltage: | 24 VDC (16 to 28 VDC) |
Current consumption: | ≤ 0.2 mA (Standby) ≤ 1.5 mA (Active) |
Cable specification: | ≥ 1.0 mm² |
No. of cable cores: | 2 |
Terminals: | 6 |
Isolation: | Isolation voltage: 8V Reconnect voltage: 11V Switch current: 1A Leakage current: 7.5 mA Series resistance: 0.15 Ω |
Vandal proof: | No |
Colour: | White (RAL 9016) |
Material (body): | ABS |
Mounting type: | DIN rail, surface |
Operating temperature: | -10 to +55°C |
Relative humidity: | ≤95%, non-condensing |
IP rating: | IP20, indoor |
Regulatory: | CE, REACH, RoHS, WEEE compliant CPR, EN-17, LPCB marked / certified |
