Global Fire VALKYRIE ASBI IP65 Addressable Wall Mount Sounder Beacon with Isolator (Black) (VALKYRIE-ASBI-IP65-BLK)
SKU
VALKYRIE-ASBI-IP65(BLK)
£107.88
£89.90
Global Fire VALKYRIE ASBI IP65 Addressable Wall Mount Sounder Beacon with Isolator (Black) (VALKYRIE-ASBI-IP65-BLK)
- Buy 10 for £106.21 £88.51 each and save 2%
- Buy 20 for £102.90 £85.75 each and save 5%
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Global Fire VALKYRIE ASBI IP65 Addressable Wall Mount Sounder Beacon with Isolator (Black) (VALKYRIE-ASBI-IP65-BLK)
The Global Fire VALKYRIE-ASBI-IP65(BLK) is a black wall-mounted addressable sounder/beacon with low power consumption. It is specifically designed to be used outdoors. Up to 32 individually addressed sounders can be installed per loop, using the address range 94 to 125.
When individual address reporting is not required, VALKYRIE AS IP65 can be configured as a shadow sounder so the sounders don’t occupy an address in the loop and therefore free up addresses for more detection devices. Shadow sounders do not report back to the control panel so their presence on the loop is not monitored.
Key Features of the VALKYRIE-ASBI-IP65(BLK) |
|---|
|
> Wall mounted
> Black Addressable Sounder Beacon c/w Isolator > For outdoor use, IP65 > Low power consumption > Address is set using switches 1 - 5 of the 8-way DIL switch > Up to 32 individually addressed sounders per loop (occupying address 94-125) > 4 selectable tones (use switches 6&7) > Can be configured as a shadow sounder (shadow sounders do not report back to the control panel - they draw current from the loop - 10 mA in alarm - and must be included in loop load calcs) |
| Brand | Global Fire Equipment |
|---|---|
| Manufacturer Part No. | VALKYRIE-ASBI-IP65(BLK) |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | GFE ZEOS |
| Colour | Black |
| Warranty | 10 Years |
Write Your Own Review
FAQ’s for Global Fire VALKYRIE ASBI IP65 Addressable Wall Mount Sounder Beacon with Isolator (Black) (VALKYRIE-ASBI-IP65-BLK)
No questions yet. Be the first to ask the question!
Product Specification for Global Fire VALKYRIE ASBI IP65 Addressable Wall Mount Sounder Beacon with Isolator (Black) (VALKYRIE-ASBI-IP65-BLK)
| Product code: | VALKYRIE-ASBI-IP65(BLK) |
| Dimensions: |
D: 112mm x H:110mm (incl. base) |
| Supply voltage: |
Loop powered - 20V to 30V DC |
| Loop Current - Quiescent: |
550 uA max. with isolator |
| Loop current - Sounder/Beacon active: | 10mA - 280W @ 28V DC, isolator incl. |
| Max. sounder output: | 100 dB (@ 1 meter - 30V DC) |
| Reset/start-up times: |
20 seconds max. |
| Protection category: | IP65 - Type B - Outdoor use |
| Operation temperature: | -25oC to +70oC |
| Max. cable size: | 0.5 - 2.5mm2 |
| Max. humidity: | 95% RH Non-Condensing |
| Colour / case material: | Black / ABS & PC |
| Weight: | 315g incl. base, 350g incl. packaging |
