Global Fire Addressable 1 Zone Monitoring Module (GFE-ZMU-1)
- Buy 10 for £53.40 £44.50 each and save 2%
- Buy 20 for £51.73 £43.11 each and save 5%
Product Details for Global Fire Addressable 1 Zone Monitoring Module (GFE-ZMU-1)
The Global Fire GFE-ZMU-1 is a fully monitored addressable module which is used to connect a single addressed zone of current-limited conventional detection devices to GFE’s addressable control panel via the detection loop.
The module requires an external 24V DC power supply and a green LED indicates supply presence. The GFE-ZMU-1 provides active end of line monitoring. The module is compliant with Standard BS5839 Detector Removal when Schottky diodes are added to detector bases.
The detection zones and their supply voltage are optically isolated from the addressable detection loop which enables the use of a local power supply. If that supply fails, a fault condition is reported at the control panel.
The status of each zone is indicated by two LEDs. A red LED signals fire, a yellow LED indicates a fault on that zone. The normal state is indicated by neither LEDs being illuminated.
Key Features of the GFE-ZMU-1 |
|---|
|
> Fully monitored addressable module
> Interface 1 conventional detection zone > Can be programmed to respond as a Zone Monitor, Flame Detector, Beam Detector, Aspirating module or Linear Heat Device > Requires 24V DC power supply power supply (green LED indicates supply presence) > 2 LEDs indicate status of zone - red signals Fire, Yellow indicates Fault on the zone (normal state = neither LED being illuminated) > Use to connect an individually addressed zone of current-limited conventional detectors to the GF addressable control panel via detection loop |
| Brand | Global Fire Equipment |
|---|---|
| Manufacturer Part No. | GFE-ZMU-1 |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Number of Zones | 1 |
| Protocol Compatibility | GFE ZEOS |
| Colour | White |
| Warranty | 10 Years |
FAQ’s for Global Fire Addressable 1 Zone Monitoring Module (GFE-ZMU-1)
Product Specification for Global Fire Addressable 1 Zone Monitoring Module (GFE-ZMU-1)
| Product code: | GFE-ZMU-1 |
| Dimensions: |
W:150mm x L:90mm x H:32mm |
| Supply voltage/loop current: |
20V to 30V DC / 1.6mA |
| Ext. Supply current @ 24V DC: |
5.3 MA Quiescent - per zone OC/SC/FIRE - 7/ 33 / 23 mA |
| Operation temperature: | -10oC to +50oC |
| Max. Cable size: | 2.5mm2 |
| Max. humidity: | 95% RH Non-Condensing |
| Colour/Case material: | White & Transparent / ABS & PC |
| Weight: | 220 boxed |
