Fike Sita Addressable Multipoint ASD Interface Boxed Module V3 (803-0005)
SKU
803-0005
£38.39
£31.99
Fike Sita Addressable Multipoint ASD Interface Boxed Module V3 (803-0005)
In Stock
Product Details for Fike Sita Addressable Multipoint ASD Interface Boxed Module V3 (803-0005)
The Fike 803-0005 is an addressable multi-function auxiliary I/O unit mounted within a single gang box for local use at the detector. Relay output to provide shutdown facilities with 30V DC 0.5A rated SPCO relay contacts and monitored input facility. Connects to the multipoint or ASD detector.
Key Features of the 803-0005 |
|---|
|
> Provide input or output via ASD detector on a Fike Sita addressable systems.
> Output relay rated at 30V DC 0.5A. > Supplied in single-gang box enclosure. |
| Brand | Fike |
|---|---|
| Manufacturer Part No. | 803-0005 |
| Product Series | SITA |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Fike SITA |
| Warranty | 2 Years |
Write Your Own Review
FAQ’s for Fike Sita Addressable Multipoint ASD Interface Boxed Module V3 (803-0005)
No questions yet. Be the first to ask the question!
Product Specification for Fike Sita Addressable Multipoint ASD Interface Boxed Module V3 (803-0005)
- Voltage Range : 24 to 42V DC
- PSU Input Voltage : 24 to 32v DC
- LED Indication :
- Active : LED on
- Contact Rating :
- Output : 30V DC 0.5A
- Operating Temperature : -10°C to +50°C
- Dimensions : 86x86x41mm
