Fike Sita Addressable Conventional Zone Module (803-0010)
SKU
803-0010
£84.42
£70.35
Fike Sita Addressable Conventional Zone Module (803-0010)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Fike Sita Addressable Conventional Zone Module (803-0010)
The Fike 803-0010 is an addressable Conventional Zone module mounted within a standard double gang box. Provides the facility to connect 1 zone of conventional resistance-monitored devices to the addressable system, up to a maximum of 20mA. EOL capacitors included. Connects to the addressable loop.
Key Features of the 803-0010 |
|---|
|
> Allows connection of a conventional zone of detectors to be interfaced to a Fike addressable system
> Supplied with double gang back box > Connects directly to the addressable loop |
| Brand | Fike |
|---|---|
| Manufacturer Part No. | 803-0010 |
| Product Series | SITA |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Fike SITA |
| Warranty | 2 Years |
Write Your Own Review
FAQ’s for Fike Sita Addressable Conventional Zone Module (803-0010)
No questions yet. Be the first to ask the question!
Product Specification for Fike Sita Addressable Conventional Zone Module (803-0010)
- Operating Temperature : -10°C to +50°C
- Voltage Range : 24 to 42v DC
- Input :
- EOL : 10 μF to 22uF capacitor
- Firing resistor : 680R
- Zone Capacity : 20mA / maximum of 20 conventional devices
- LED Indication :
- Normal : 20s interval
- Fault : 5s interval
- Activated : 0.3s interval
- Dimensions :
- Overall : 146x87x41mm
- Back Box : 146x87x32mm
