Siemens FDCI723 Cerberus PRO Zone Module (Requires External 24V DC Supply) (S54322-F6-A1)
SKU
S54322-F6-A1
£90.56
£75.47
Siemens FDCI723 Cerberus PRO Zone Module (Requires External 24V DC Supply) (S54322-F6-A1)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Siemens FDCI723 Cerberus PRO Zone Module (Requires External 24V DC Supply) (S54322-F6-A1)
Siemens FDCI723 Cerberus PRO Zone Module, external powered, C-NET.
* A detector line (collective or conventional 110 series, DS11, SynoLINE 300/600) can be connected to the C-NET
* LED indicator for detector line status: fault, test, etc.
* Two-wire installation for all cable types
* DC 24 V power supply, external (detector lines electrically isolated)
* Microprocessor-controlled signal processing
* Communication via C-NET (addressed individually)
* Can be used in dry, dusty, and humid areas
* Different mounting options
* Zone module incl. 1 Transzorb diode 20 V and 2 mounting feet for TS35 U-rail
Key Features of the S54322-F6-A1 |
|---|
|
> 1 detector line (collective or conventional 110-series, DS11, SynoLINE300/600)
> Electrical isolation between C-NET and collective/conventional detector line > LED indicator showing status of detector line: fault, test, etc. > Two-wire installation for all cable types > DC 24 V external power supply > Microprocessor-controlled signal processing > Communication via C-NET (addressed individually) > Can be used in dry, dusty, and damp areas > Different mounting option > Transparent housing, ensuring that LED indicators are easy to see > Protected electronics > Integrated line separator > Easy mounting using snap fastener > Can be used in dry areas > Housing FDCH221 can be used in dusty and humid environments |
| Brand | Siemens |
|---|---|
| Manufacturer Part No. | FDCI723 |
| Product Series | Cerberus PRO |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Siemens Cerberus |
| Colour | White |
| Warranty | 5 Years |
Write Your Own Review
FAQ’s for Siemens FDCI723 Cerberus PRO Zone Module (Requires External 24V DC Supply) (S54322-F6-A1)
No questions yet. Be the first to ask the question!
Product Specification for Siemens FDCI723 Cerberus PRO Zone Module (Requires External 24V DC Supply) (S54322-F6-A1)
| Product: | Siemens Zone Module |
| Product code: | S54322-F6-A1 |
| Dimensions: |
W:95mm x H:71mm x D:23mm |
| Standard: | EN 54-17 , EN 54-18 |
| Operating voltage: | DC12 - 33V |
| EOL resistor: | 20 V transzorb diode or EOL22(Ex) |
| Operating temperature: | -10 to +50oC |
| Storage temperature: | -30 to +75oC |
| Cable capacity: | 0.2 - 1.5mm2 |
| System compatibility: | C-NET -> FS720 |
| Communication protocol: | C-NET |
| Detector line: | 110 series / DS11, SynoLINE300/600 |
| Quiescent current: | Max. 0.3 mA |
| Relative humidity: | ≤95 % rel. |
| Colour: | Pure White (RAL9010) |
| Protection category: | IP30; IP65 with ext. housing |
