ESP Beacon Accessible Toilet Alarm Power, Light & Buzzer Module (White) (UDTAPLBM)
SKU
UDTAPLBM
£25.16
£20.97
ESP Beacon Accessible Toilet Alarm Power, Light & Buzzer Module (White) (UDTAPLBM)
- Buy 10 for £24.78 £20.65 each and save 2%
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for ESP Beacon Accessible Toilet Alarm Power, Light & Buzzer Module (White) (UDTAPLBM)
This standalone Beacon Accessible Toilet Alarm Power Light & Buzzer Module, White (UDTAPLBM) is an accessory for use with the UDTAKIT, used to raise an alert for assistance. A red LED indicator illuminates when in alarm state. It has a distinctive, 80dB audible alert. Made from anti-microbial ASB and comes with a surface back box and user manual.
Key Features of the UDTAPLBM |
|---|
|
> For use with UDTA Kit
> Clear alarm LED alert > 80db distinctive audible alert > 240vac Input for system power > Complete with battery back-up function (Battery Included) > Antimicrobial properties > Compete with surface back box |
| Brand | Elite Security Products |
|---|---|
| Manufacturer Part No. | UDTAPLBM |
Write Your Own Review
FAQ’s for ESP Beacon Accessible Toilet Alarm Power, Light & Buzzer Module (White) (UDTAPLBM)
No questions yet. Be the first to ask the question!
Product Specification for ESP Beacon Accessible Toilet Alarm Power, Light & Buzzer Module (White) (UDTAPLBM)
| Code: | UDTAPLBM |
| Description: | Beacon Accessible Toilet Alarm Power Light & Buzzer Module, White |
| Supplied: | 1 x Backbox, Installation Bolts, User Manual |
| IP Rating: | IP20 |
| Accessories: | UDTALBM: Assistance Alarm Light and Buzzer Module UDTAPCM: Assistance Alarm Pull Cord Module UDTASPC: Assistance Alarm Replacement Pull Cord UDTAREM: Assistance Alarm Reset Module |
| Dimensions: | Plate size 87mm x 87mm x 41mm (single gang) |
| Operating voltage: | 100 - 230 VAC |
| Max. cable size: | 1.5mm² |
| Power consumption: | 0.2A |
| Battery backup: | A23 battery |
| Inputs: | Type: Ground & 2 live circuits - X1 & X2 Activation type: Energise with a Normally Open Clean Contact |
| Outputs: | Number of outputs: 2 Type:1 Switched Live sharing common ground Separate output for additional sounders Rating: 12V 500mA |
| Indicator: | LED illuminates red when in alarm state |
| Material: | Anti-Microbial ABS |
| Colour: | White |
| Mounting: | Surface or flush (surface box included) |
| Buzzer sound level: | >80dB, when activated |
| Purpose: | Activation and Reset Circuits |
| Warranty: | 2 years |
