Eaton Cooper Intelligent Addressable Wall Sounder VAD (Red Flash) (CASB483)
SKU
CASB483
£102.67
£85.56
Eaton Cooper Intelligent Addressable Wall Sounder VAD (Red Flash) (CASB483)
- Buy 10 for £100.27 £83.56 each and save 2%
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Eaton Cooper Intelligent Addressable Wall Sounder VAD (Red Flash) (CASB483)
A market-leading sounder and the latest EN 54-23 compliant beacon; providing clear audible and visual signalling in the event of an emergency.
The intelligent addressable wall sounder visual alarm device (VAD) offers an impressive performance and a proven, durable design that you can rely on.
The CASB483 is suitable for fire notification in commercial buildings.
Key Features of the CASB483 |
|---|
|
> Soft addressed
> Red housing > Red flash > Compliant to the latest standards (EN 54-23) > LED technology for long service life and low current consumption > Coverage switch feature; switch from 7.5m to 2.5m reducing power consumption by up to 50% > Reduce flash from 1Hz to 0.5Hz to reduce power consumption by up to 50% > Proven, industry leading sounder offers durable and reliable notification > Uses Eaton’s patented lens design that optimises light dispersal |
| Brand | Eaton |
|---|---|
| Manufacturer Part No. | CASB483 |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Eaton |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Eaton Cooper Intelligent Addressable Wall Sounder VAD (Red Flash) (CASB483)
No questions yet. Be the first to ask the question!
Product Specification for Eaton Cooper Intelligent Addressable Wall Sounder VAD (Red Flash) (CASB483)
| Product: | Eaton Addressable Wall Sounder VAD |
| Catalogue no.: | CASB483 |
| Dimensions: | W:106mm x H:147mm x D:92mm |
| Supply voltage: |
19 - 30V dc |
| Standby current: | <330μA |
| Operating current: | 13.4 - 4.75mA (depending on setting/LED colour) |
| Mounting height: (x) |
2.4m |
| Coverage: (y) |
7.5m (switchable 2.5m) |
| Coverage volume code (w-y-x): |
W2.4 - 7.5 (W2.4-2.5) |
| Flash rate: |
0.5Hz (Switchable to 1Hz) |
| Operating temperature: |
-10oC to +55oC |
| IP rating: |
IP21C |
| Flash colour: | Red |
| Housing colour: | Red |
| Sound output: |
99dB(A) Two tone 644/984Hz @ 1Hz cycle |
| Mounting: | Surface, Wall |
