Product Details for Eaton Cooper Intelligent Addressable Ceiling VAD (White Flash, Shallow Base) (CAB492CS)
The Eaton CAB492CS is an EN 54-23 certified, low-current and attractive fire alarm beacon that provides clear notification in the event of fire.
The addressable visual alarm device (VAD) is suitable for ceiling mounting and a variety of applications. It is compatible with a shallow base.
The VAD has a unique lens design that distributes light in a cylindrical shape to achieve the required illumination specified by the latest standards, whilst using minimum current consumption.
Designed in accordance with CoP 0001 (UK installation code) for mounting at a height of up to 3m and with an attractive appearance, the device is a desirable and reassuring safety presence in any building.
Key Features of the CAB492CS |
|---|
|
> Soft addressed
> Shallow base > Red housing > White flash > Compliant to the latest standards (EN 54-23) > Ultra-low current consumption > Coverage switch - 7.5m to 2.5m > Flash rate switch from 1Hz to 0.5Hz reduces power consumption by up to 50% > Attractive, discrete design suitable for public places |
| Brand | Eaton |
|---|---|
| Manufacturer Part No. | CAB492CS |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Eaton |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Eaton Cooper Intelligent Addressable Ceiling VAD (White Flash, Shallow Base) (CAB492CS)
No questions yet. Be the first to ask the question!
Product Specification for Eaton Cooper Intelligent Addressable Ceiling VAD (White Flash, Shallow Base) (CAB492CS)
| Product: | Eaton Addressable Wall VAD, Shallow base |
| Catalogue no.: | CAB492CS |
| Dimensions: | W:93mm x H:93mm x D:38mm |
| Operating current: | 12.5-45mA (depending on setting & LED colour) |
| Standby current: | <330μA |
| Mounting height (x): |
2.4m |
| Coverage (y): |
7.5m (switchable 2.5m) |
| Coverage volume (c-x-y): | C-2.4 - 7.5 |
| Flash rate: | 0.5 Hz (Switchable to 1Hz) |
| Flash colour: | White LED |
| Operating temperature: |
-10oC to +55oC |
| IP rating: | IP33C |
| System typology: | Addressable |
| Material: | PC/ABS |
| Colour housing: | Red |
| Mounting: | Surface, Wall |
