Eaton CF2000 Cooper 2 Loop Addressable Fire Alarm Panel
Discontinued
Alternative Products
Product Details for Eaton CF2000 Cooper 2 Loop Addressable Fire Alarm Panel
The Eaton Cooper CF2000 is an entry-level intelligent addressable control panel which can be configured for either 1 or 2 loop operation, and is certified to EN54 parts 2 & 4.
The panel has a graphic display, providing a simple menu-driven end-user interface. With the CF2000’s ability to support Eaton cause and effect programming and a range of user controllable functions, it makes the panel suitable for a varied range of projects from small warehouses to small/medium office developments as well as many small industrial applications.
As with all Eaton intelligent addressable panels, the CF2000 uses “spur tolerant” soft addressing to minimise installation time and remove the potential for errors often associated with many forms of manual addressing.
System Configuration
The CF2000 can be configured to operate as a 1 or 2 loop panel. Using Eaton system protocol the panel “auto learns” the equipment mounted on the loop(s) and “soft addresses” each item, ensuring a simple setup procedure and reducing the time required for system setup.
All loop-mounted equipment has integral short circuit isolators, ensuring loop integrity is maintained should a short circuit fault occur on the loop.
A comprehensive range of interface units are available and compatible with the CF2000.
Installation
The CF2000 has been designed with ease of installation as a major objective.
The panel back box can be surface mounted with cable entry points to both the top and rear. The mother board and integrated power supply are mounted on a sub chassis which is easily removed to aid panel fitting.
Back box mounting is further assisted with the provision of a drill template allowing the mounting screw holes to be pre-drilled and the top two mounting screws fitted prior to final positioning of the back box.
Ample room is provided within the back box for the termination of external cables and bonding of cable screen wires.
Key Features of the 910187FULL-0198 |
|---|
|
> Configurable as a 1 or 2 loop panel
> Up to 200 addresses per loop > Up to 60 sounders/ beacons/20 I/Os, subject to loop loading calculations > Soft addressing > Menu-driven graphic screen > Multi-language selection capability > Integral battery and power supply > 2x7Ah batteries included > Easy to operate end user controls > Full system integrity with Eaton developed protocol > Core range of compatible devices > 4 sounder circuits > Monitored for open and short circuit (max 3.0A combined) |
| Brand | Eaton |
|---|---|
| Manufacturer Part No. | CF2000 |
| Primary Power Source | Mains Powered (230V) |
| System Type | Addressable |
| Number of Loops (Fitted) | 2 |
| Max No. of Loops Possible | 2 |
| Number of Zones | 32 |
| Protocol Compatibility | Eaton |
| Colour | Grey |
| Warranty | 1 Year |
FAQ’s for Eaton CF2000 Cooper 2 Loop Addressable Fire Alarm Panel
Product Specification for Eaton CF2000 Cooper 2 Loop Addressable Fire Alarm Panel
| Product: | Eaton Addressable 2 Loop Control Panel, Standalone |
| Catalogue no.: | 910187FULL-0198 |
| Dimensions: | W:320mm x H:400mm x D:170mm |
| Standards: | EN54 Pt2 1997, A1:2006 EN54 Pt 4 1997, A1:2002 & A2:2006 |
| No. of loops: |
2 |
| Addresses per loop: |
200 |
| Panel sounder circuits: | 4 outputs, 1A total (programmed in pairs - outputs 1&2, 3&4) |
| Class change facility: | Operated by external, normally open, volt free contacts |
| Auxiliary relay: | One set of change over contacts, operated in the event of fire activation |
| Routing equipment output: | Monitored 24V dc, 30mA (max) auxiliary fire |
| Protection equipment output: | Monitored 24V dc, 30mA (max) auxiliary fault |
| Routing equipment output: | Monitored 12Vdc, 30mA (max) |
| Mains input voltage: | 230V ac +10%/-15% |
| Operating voltage: | 24V dc |
| Batteries: | 2 x 12V 7Ah |
| Standby duration: | 24 hrs (dependant on loop loading) |
| Operating temperature: | -5oC to +40oC (93% max humidity, non condensing) |
| Construction: | Back box - mild steel, door - PC/ABS |
| Colour: | Graphite |
| IP rating: | IP30 |
| Cable entry: | Top: 20 entry cable knockouts (20mm) Rear: 7 entry cable knockouts (20mm) |
| Weight: | 15 kg |
