C-TEC Quantec Corridor Display with controls
SKU
QT608C
£165.78
£138.15
C-TEC QT608C Quantec Corridor Display
In Stock
Product Details for C-TEC Quantec Corridor Display with controls
The C-TEC QT608C Quantec is a Corridor Display with a 16-character x 2 line display to indicate incoming calls in corridors/rooms/stations
Key Features of the QT608C |
|---|
|
> Quantec Corridor Display
> 16 character x 2 line display indicates incoming calls in corridors/rooms/stations etc > Includes an onboard sounder and buttons to accept/scroll through/manually call divert > Shows call type/location/User ID or name of person calling > Highest priority calls shown first with message saying how many calls are waiting > Flash/sounder rates intensify to reflect urgency of incoming calls > Adjustable contrast/volume > External sounder connection |
| Brand | C-TEC |
|---|---|
| Manufacturer Part No. | QT608C |
Write Your Own Review
FAQ’s for C-TEC Quantec Corridor Display with controls
No questions yet. Be the first to ask the question!
Product Specification for C-TEC Quantec Corridor Display with controls
| Dimensions: |
W:146mm x H: 87mm x D:35mm Mount on a 35mm deep back box |
| Power requirements: | Nominal 24V DC (from Quantec Controller/Network) |
| Quiescent current: | 5mA (with back light off) |
| Indicators: | 2 line x 16 character backlit LCD display |
| Controls: | Accept (A); Scroll Up; Scroll Down; Adjust contrast; Adjust volume; Adjust volume; Enable internal/external beeper |
| Connections: | Net +; Net - |
| Expansion connections: | External sounder connection (current sink to the NET- line rated at 30V, 30mA, 300 mW dissipation max.) |
| Onboard sounder: | Yes |
| Onboard Infrared receiver: | No |
| IP Rating: | IP40 |
| Construction & finish: | Plastic |
| Operating temperature: | -5oC to +40oC max humidity 95% |
| Weight: | 166g |
