C-TEC Quantec Controller
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for C-TEC Quantec Controller
The C-TEC QT601-2 Quantec Controller supplies power to and controls a Quantec Addressable Call System
Key Features of the QT601-2 |
|---|
|
> Monitors network devices
> Manages routing/distribution of all calls > Provides connections for network wiring, standby batteries, laptop, optional paging/DECT equip. > Library of 40 pre-set & 45 custom place names > System setup requires laptop running QT707 programming tools > Semi- (QT385) or fully- (BF359/3S) flush mount > System wiring requires one or more QT603 splitters > Wiring should be made in spine/limb arrangement using 1.5-2.5mm2 T & E (spines) & 4-8 core stranded security cable (limbs) |
| Brand | C-TEC |
|---|---|
| Manufacturer Part No. | QT601-2 |
Write Your Own Review
FAQ’s for C-TEC Quantec Controller
No questions yet. Be the first to ask the question!
Product Specification for C-TEC Quantec Controller
| Dimensions: |
W:410mm x H:250mm x D:80mm (base); W: 439mm x H:274mm x D:7mm (lid) |
| Mains supply: | 230V 50/60 HZ |
| Mains rated current: | 350mA max. |
| Internal power supply: | 27 dc nominal |
| Total output current: |
Limited to 3A@ 230Vac |
| Quiescent current: | 100mA @ 24V |
| Max. battery size & type: | 2 x 12V 7Ah VRLA connected in series |
| Open collector outputs: | OP1 (active on standard call); OP2 (active on help req. call); OP3 (active on emergency call); OP4 (active on attack call); OP5 (failsafe fault output). Voltfree single pole c/o max. switch current |
| Other outputs: | 24V Aux. Power (19.5V min, 28V max). Protected by a resettable fuse. Max. current 100mA |
| PC connection: | CONN1 provides an RS232 connection for use with Quantec Surveyor data management software via PC or Quantec Printer |
| Indicators: | 2 line x 40 character backlit display; Power LED (lit when power is present, off when no power present) |
| Controls: | Accept (A); Scroll Up; Scroll Down; Code Entry Buttons (1,2,3 & 4); Escape (E) |
| Connections: | Plus-on type, largest acceptable conductor size 1mm2 |
| Expansion connections: | CONN2 provides an RS232 connection for paging equipment |
| IP Rating: |
IP30 |
| Construction & finish: | Metal base, plastic lid |
| Operating temperature: | -5oC to +40oC max humidity 95% |
| Weight: | 3.5kg |
