C-TEC Hand/Foot Operated Pneumatic Pad
SKU
NC805P
£81.05
£67.54
C-TEC NC805P Hand/Foot Operated Pneumatic Pad
- Buy 10 for £77.93 £64.94 each and save 4%
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for C-TEC Hand/Foot Operated Pneumatic Pad
The C-TEC NC805P is a Hand/Foot Operated Pneumatic Pad for those who find it difficult to press buttons on standard call leads.
Key Features of the NC805P |
|---|
|
> Hand/foot operated pneumatic pad
> Easier to press than button on standard tail call lead > Operates NC805AS air switch which, when appropriately connected, triggers a standard call. > IP20 rated |
| Brand | C-TEC |
|---|---|
| Manufacturer Part No. | NC805P |
Write Your Own Review
FAQ’s for C-TEC Hand/Foot Operated Pneumatic Pad
No questions yet. Be the first to ask the question!
Product Specification for C-TEC Hand/Foot Operated Pneumatic Pad
| Dimensions: | Dia:95mm x D:20mm. 2m PVC tubing |
| Compatibility: | C-TEC's Quantec & 800 Series Call Systems, Must be used with NC805AS Air Switch |
| Quiescent current: | 0mA (none) |
| Alarm current: | Determined by type of control equipment and number/type of field devices connected to system |
| Indicators: | Reassurance LED on host call point illuminates steadily when host NC805AS is activated and/or removed |
| Controls: | Applying sufficient pressure causes air switch to activate and generate a standard call if connected to compatible Quantec/800 Series call point) |
| Connections: | End of PVC tubing connects to spigot on end of NC806AS Air Switch |
| Onboard sounder: | No |
| Onboard infrared receiver: | No |
| Construction & finish: | PVC |
| IP rating: | IP20 |
