C-TEC 10 Zone Master Call Controller c/w 300mA PSU, surface mount
SKU
NC910S
£198.37
£165.31
C-TEC NC910S -10 Zone Master Call Controller c/w 300mA PSU, surface mount
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for C-TEC 10 Zone Master Call Controller c/w 300mA PSU, surface mount
The C-TEC NC910S is a 10 Zone Master Call Controller supplied with a 12V 300mA PSU and 2 volt free relay contacts that activate on a standard or emergency call. Surface Mounted.
Key Features of the NC910S |
|---|
|
> 10 Zone Master Call Controller
> 12V 300mA PSU supplied > 2 volt-free relay contacts included > Surface mounted > 800 Series compatible > Attractive plastic enclosure > Two call levels - standard (constant tone), emergency (intermittent tone) > Optional mute and call accept/reset buttons > Slide-in labelling system > Zones can be wired in 4 or 6 core (7/02) stranded security cable > Additional master/expansion units available |
| Brand | C-TEC |
|---|---|
| Manufacturer Part No. | NC910S |
Write Your Own Review
FAQ’s for C-TEC 10 Zone Master Call Controller c/w 300mA PSU, surface mount
No questions yet. Be the first to ask the question!
Product Specification for C-TEC 10 Zone Master Call Controller c/w 300mA PSU, surface mount
| Dimensions: |
W:214mm x H:178mm x D:70mm Surface mounting |
| Mains Supply: | 230V 50/60 Hz (36mA max. current) |
| Internal Power Supply: | 11V dc (300mA max. current when powered by Mains) |
| Quiescent current: | 0mA (none) |
| Auxiliary relays: | 2 volt free relay contacts (NO/C/NC). Activate when standard or emergency call is received by the controller. Both relays rated at 30V dc @ 1A |
| Auxiliary inputs: | External PSU Input: 9V-15C dc @ 400mA (suitable for use with an BF560-12 12V 2A boxed PSU which has space available for a 12V 7AH battery) |
| Alarm current: | Determined by type of control equipment and number/type of field devices connected to system |
| Indicators: | Green Power on LED; 10 red Zonal Alarm LEDs (lit steady for a standard call, pulse for an emergency call); Internal buzzer (on steady for any standard call; intermittent for any emergency call). |
| Expansion connections: | CONN2 allows the connection of 1 x NC910EF 10 zone expansion unit or 1 x NC920EF 20 zone expansion unit |
| Controls: | 2 buttons - (A) Reset or inactive; (B) Mute or Call Accept (Both buttons are link selectable). If Call Accept is selected indicators on relevant field devices will emit a slow intermittent tone |
| Call acknowledgement functionality: | Yes |
| Construction & finish: | Plastic detachable lid and back box RAL7035 |
| Operating temperature: | -5oC to +40oC, 95% humidity non-condensing |
| IP Rating: | IP41 |
| Weight: | 1.27kg |
