Apollo XPander Input / Output Single Unit (XPA-IN-14011-APO)
Limited Stock
Product Details for Apollo XPander Input / Output Single Unit (XPA-IN-14011-APO)
The Apollo XPander Input/Output Unit is a radio based interface and offers two monitored input circuits and two relay outputs. It can be used for controlling fire doors, fire dampers, smoke vents and other fire engineering applications.
Radio Communications
Fire detection systems are life-saving systems and must, therefore, be highly reliable in use. Radio communications have been developed to a point where high reliability can be guaranteed, provided that the rules for the design of radio systems and installation are carefully observed.
Radio communication technology in the detection has matured to the point where a standard has been drawn up as part of the EN54 family of standards for components of a fire detection system. The standard is EN54 Part 25.
Frequency
The frequency used by XPander is 868MHz which is the harmonised European radio frequency.
Watch the Video
Key Features of the XPA-IN-14011-APO |
|---|
|
> Wireless Single I/O Unit
> Monitored switch circuit > Voltage-free contacts > Capable of switching up to 30V at 1A > Five-year battery life using standard AA alkaline batteries |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | XPA-IN-14011-APO |
| Primary Power Source | Longlife Batteries (Lithium) |
| System Type | Wireless |
| Protocol Compatibility | Apollo XP95, Apollo Discovery, Apollo CoreProtocol |
| Colour | Grey |
| Warranty | 10 Years |
FAQ’s for Apollo XPander Input / Output Single Unit (XPA-IN-14011-APO)
Product Specification for Apollo XPander Input / Output Single Unit (XPA-IN-14011-APO)
| Product code: | XPA-IN-14011-APO |
| Description: | Apollo XPander Input/Output Module |
| Dimensions: | W:120mm x L:120mm x D:60mm |
| Colour: | Grey |
| Approval: | CPR |
| Operating temperature: | -10 to 55°C |
| Humidity: | 0% to 95% (no condensation or icing) |
| Warranty: | 10 year |
| Weight: | 620g |
