Apollo Intelligent Open-Area VAD Cat. W - White Body (Red Flash) (W-3.1-9) (SA5501-501APO)
SKU
SA5501-501APO
Intelligent Open-Area VAD Cat. W - White Body (Red Flash) (W-3.1-9) (SA5501-501APO)
Unavailable
Product Details for Apollo Intelligent Open-Area VAD Cat. W - White Body (Red Flash) (W-3.1-9) (SA5501-501APO)
This Apollo Open Area Category-W Visual Alarm Device (VAD) provides an intense visual alarm in situations where a sounder alarm type would not suffice, e.g. in a noisy workshop / machine room or in areas where deaf or hearing-impaired people may be present. White body, Red flash.
Key Features of the SA5501-501APO |
|---|
|
> EN54-23 Compliant ‘Category W’ VADs
> White body, Red flash > Built-in controllable isolator (when used with XPERT 8 Base) > Configurable coverage volume, High & Low setting > Easy installation on Apollo XPERT 7 or 8 Base |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | SA5501-501APO |
Write Your Own Review
FAQ’s for Apollo Intelligent Open-Area VAD Cat. W - White Body (Red Flash) (W-3.1-9) (SA5501-501APO)
No questions yet. Be the first to ask the question!
Product Specification for Apollo Intelligent Open-Area VAD Cat. W - White Body (Red Flash) (W-3.1-9) (SA5501-501APO)
| Specifications typical at 24V, 25oC and 50% RH unless otherwise stated | |
|---|---|
| Product dimensions: | Diameter:100mm x D:40mm |
| Material: | Housing: White flame retardant polycarbonate Terminals: Tin-plated stainless steel |
| Supply voltage: | 17V - 35VDC |
| Digital communication: | CoreProtocol, Discovery and XP95 |
| Quiescent current: | 1.2mA |
| Coverage: | High 14mA Low 9.5mA |
| Flash rate: | 0.5Hz |
| Operating temperature: | -10 ºC to +55ºC |
| Storage temperature: | -10 ºC to +55ºC |
| IP Rating: | IP21C |
| Base compatibility (sold separately): | Part No. 45681-210APO XPERT 7 Base Part No. SA5000-200APO XPERT 8 Base - White Part No. 45681-797 BESA Adaptor Plate (Pack of 5) Please note: To make use of the Short Circuit Isolator (SCI), the VAD must be installed on the SA5000-200/202 XPERT 8 Bases. |
| Standards: | EN 54-23, EN 54-17 |
| Weight: | 118g |
