Apollo Intelligent Open-Area Sounder VAD Cat. W - Red Body (Red Flash) (W-3.1-9) (SA5500-551APO)
SKU
SA5500-551APO
Intelligent Open-Area Sounder VAD Cat. W - Red Body (Red Flash) (W-3.1-9) (SA5500-551APO)
Unavailable
Product Details for Apollo Intelligent Open-Area Sounder VAD Cat. W - Red Body (Red Flash) (W-3.1-9) (SA5500-551APO)
This Apollo Open Area Category-W Sounder VAD provides both audible and visual alarms in situations where one alarm type would not suffice, e.g. in a noisy workshop / machine room or in areas where deaf or hearing-impaired persons may be present. Red body, Red flash.
Key Features of the SA5500-551APO |
|---|
|
> EN 54-3 Compliant Sounders with 101dB output
> Red body, Red flash > 7 Adjustable volume levels, 15 Tone Pairs > EN 54-23 Compliant Category W VADs > Configurable Coverage volume, High and Low setting > Built-in controllable Isolator (when used with XPERT 8 Base) > Flash rate 0.5Hz > Wide angle of visibility > Easy installation on Apollo XPERT 7 or 8 Base |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | SA5500-551APO |
Write Your Own Review
FAQ’s for Apollo Intelligent Open-Area Sounder VAD Cat. W - Red Body (Red Flash) (W-3.1-9) (SA5500-551APO)
No questions yet. Be the first to ask the question!
Product Specification for Apollo Intelligent Open-Area Sounder VAD Cat. W - Red Body (Red Flash) (W-3.1-9) (SA5500-551APO)
| Specifications typical at 24V, 25oC and 50% RH unless otherwise stated | |
|---|---|
| Product dimensions: | Diameter:113mm x D:65mm |
| Material: | Housing: Red flame retardant polycarbonate Terminals: Tin-plated stainless steel |
| Supply voltage: | 17V - 35VDC |
| Digital communication: | CoreProtocol, Discovery and XP95 |
| Quiescent current: | 1.2mA |
| Coverage: | High 19mA Low 14.5mA |
| Flash rate: | 0.5Hz |
| Max. sound output at 90o @ 1m: | 101 dB(A) |
| Operating temperature: | -10 ºC to +55ºC |
| Storage temperature: | -10 ºC to +55ºC |
| Humidity: | 0% to 95% RH (no condensation or icing) |
| IP Rating: | IP21C |
| Standards: | EN 54-23, EN 54-17, EN54-3 |
| Weight: | 214g |
