Apollo Intelligent Marine Base Mounted IR3 Flame Detector (55000-029MAR)
SKU
55000-029MAR
£1,200.46
£1,000.38
Apollo Intelligent Marine Base Mounted IR3 Flame Detector (55000-029MAR)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Apollo Intelligent Marine Base Mounted IR3 Flame Detector (55000-029MAR)
The Apollo Marine Intelligent Base Mounted Triple Infra-Red (IR3) Flame Detectors are designed to protect indoor areas where open fires may be present.
The detector is sensitive to low frequency, flickering IR radiation emitted by flames during combustion. Since it responds to flickering radiation the detector can operate even if the lens is contaminated by a layer of oil, dust water-vapour or ice.
Key Features of the 55000-029MAR |
|---|
|
> Responds to stationary flames with no flicker
> Sensitive to low-frequency flickering IR radiation emitted by flames during combustion > Compact flame detector which fits into Discovery Marine mounting bases > Loop-powered > False alarms due to factors such as flickering sunlight are avoided by a combination of filters and signal-processing techniques > Suitable for use in marine applications |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | 55000-029MAR |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Apollo XP95, Apollo Discovery, Apollo CoreProtocol |
| Sensor Type | Triple Infrared (IR³) |
| Detectable Medium | Flame |
| Colour | White |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Apollo Intelligent Marine Base Mounted IR3 Flame Detector (55000-029MAR)
No questions yet. Be the first to ask the question!
Product Specification for Apollo Intelligent Marine Base Mounted IR3 Flame Detector (55000-029MAR)
| Product code: | 55000-029MAR |
| Description: | Apollo Intelligent Marine Base Mounted IR3 Flame Detector |
| Dimensions: | Diameter:100mm x D:40mm |
| Materials: | Housing: Polycarbonate Terminals: Nickel plated stainless steel |
| Colour: | White |
| Sensing window: | Material: Float glass Thickness: 2mm |
| Standards / Approvals: | EN-54-10 / KRS |
| Range of view @ 25m: | 0.1m² n-heptane |
| Field of view: | 90° |
| Spectral response - IR: | 0.75 to 2.7μm |
| Sensitivity: | High-Class 1 Low-Class 3 |
| Chamber type: | Chevron |
| Protocol voltage: | 5 to 9V peak to peak |
| Power-up surge current: | 9mA |
| Max. power-up time: | 4 seconds |
| Quiescent current: | 2500μA |
| Supply voltage: | 17 to 28V dc |
| Humidity: | 0 - 95% (no condensation or icing) |
| Operating temperature: | -40 to 70°C |
| Storage temperature: | -40 to 70°C |
| IP Rating: | IP66 |
| Warranty: | 3 year |
| Weight: | 150g |
