Apollo Intelligent Manual Call Point (Blue) (SA5900-905APO)
In Stock
Product Details for Apollo Intelligent Manual Call Point (Blue) (SA5900-905APO)
The Apollo SA5900-905APO Intelligent Manual Call Point in Blue is commonly used to manually initiate a security alert.
The manual call point signals to the Control and Indicating Equipment using an interrupt feature within the Apollo Digital Protocol. An alarm status is indicated through the rotation of the resettable element, displaying yellow and black indication bars and a solid red LED. The manual call point can be easily reset from the front using the supplied reset key.
Electrical Description
The Intelligent Manual Call Point is loop-powered and operates at 17-35V dc.
Operation
The address of each call point is set at the commissioning stage by means of a DIL switch.
A solid red alarm LED is provided on the manual call point. This LED is controlled independently of the call point, by the control panel. The LED will flash yellow if there is a fault and flash green when the device is polled. Discovery and CoreProtocol configurable.
Once activated, the Intelligent Manual Call Point can be reset by inserting the reset key into the front facing LED, turning clockwise until a positive click and reset occurs.
The Intelligent Manual Call Point incorporates a short circuit isolator which will ensure its operation in the event of a short circuit fault on the loop. Isolator operation is indicated by a solid yellow LED. For further details of the isolator refer to data sheet PP2090, available on request.
This manual call point helps reduce installation time as all the initial installation cabling is wired to a removable terminal block which fits neatly in the back of the manual call point.
Mechanical Construction
The component parts of the call point are moulded in a robust fire retardant polycarbonate.
Communication
XP95, Discovery and CoreProtocol compatible.
Backward Compatibility
The Intelligent Manual Call Point will operate with compatible Apollo control equipment using the digital XP95, Discovery and CoreProtocols.
Key Features of the SA5900-905APO |
|---|
|
> Resettable operating element
> 170° viewable LED > Suitable for semi flush or surface mounting > 'Plug and Play' terminal connections for faster wiring > Continuity link for wiring test before commissioning > XP95, Discovery and CoreProtocol compatible |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | SA5900-905APO |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Apollo XP95, Apollo Discovery, Apollo CoreProtocol |
| Colour | Blue |
| Warranty | 10 Years |
FAQ’s for Apollo Intelligent Manual Call Point (Blue) (SA5900-905APO)
Product Specification for Apollo Intelligent Manual Call Point (Blue) (SA5900-905APO)
| General | Warranty | 10 year |
| Mechanical | Colour | Blue |
| Weight | 180g | |
| Materials housing | Polycarbonate | |
| Product length | 90mm | |
| Product width | 90mm | |
| Product depth | 63mm | |
| Key type | Apollo Manal Call Point reset key | |
| Product length | 3.54in | |
| Product width | 3.54in | |
| Product depth | 2.48in | |
| Performance | Analogue value nominal | 16 |
| Alarm level analogue value | 64 | |
| Fault level analogue value | 4 | |
| Type | A | |
| Operating element | Resettable element | |
| Action | Single | |
| Electrical | Protocol voltage (max) | 13V |
| Protocol voltage (min) | 5V | |
| Protocol voltage | 5 to 13V peak to peak | |
| Power-up surge current | 1mA | |
| Maximum power-up time | 1 second | |
| Status indicator - Alarm | Red | |
| Status indicator - Fault | Yellow | |
| Status indicator - Isolate | Yellow | |
| Status indicator - Poll | Flashing green | |
| Quiescent current | 100μA | |
| Quiescent current tested at | 24V dc | |
| Supply voltage (max) | 35V dc | |
| Supply voltage (min) | 17V dc | |
| Supply voltage (Vmin-Vmax) | 17 to 35V dc | |
| Polarity | L1 & L2 are polarity sensitive | |
| Environmental | Humidity (max) | 95% RH |
| Humidity (min) | 0% RH | |
| Humidity | 0% to 95% (no condensation or icing) | |
| Humidity Note | no condensation or icing | |
| Operating temperature (min) | -40°C | |
| Operating temperature (max) | 70°C | |
| Operating temperature | -40 to 70°C | |
| IP rating Value | IP44 | |
| Operating temperature | -40 to 158°F | |
| Operating temperature (max) | 158°F | |
| Operating temperature (min) | -40°F |
