Apollo Discovery Marine Manual Call Point (58100-970MAR)
SKU
58100-970MAR
Apollo Discovery Marine Manual Call Point (58100-970MAR)
Discontinued
Alternative Products
Product Details for Apollo Discovery Marine Manual Call Point (58100-970MAR)
The Apollo 58100-970MAR Discovery Marine Manual Call Points (MCP) have been designed for use in marine and offshore environments.
Key Features of the 58100-970MAR |
|---|
|
> EN 54-11 Certified
> Reports an alarm in under 0.2 seconds > 'Plug and Play' terminal connections for faster wiring > Continuity link for wiring test before commissioning > Suitable for semi-flush or surface mounting > XP95 & Discovery compatible > Resettable operating element > Easy access, front reset mechanism > Ergonomic reset key and keyring hole > Front facing accessible addressing for commissioning > E-Z fit first fix terminals for installation (indoor only) > Flashing polling LED option > 170º viewable LED indicator |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | 58100-970MAR |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Apollo XP95, Apollo Discovery, Apollo CoreProtocol |
| Colour | Red |
| Warranty | 10 Years |
FAQ’s for Apollo Discovery Marine Manual Call Point (58100-970MAR)
No questions yet. Be the first to ask the question!
Product Specification for Apollo Discovery Marine Manual Call Point (58100-970MAR)
| Product code: | 58100-970MAR |
| Description: | Apollo Discovery Marine Manual Call Point |
| Dimensions: | W:89mm x L:93mm x D:60mm |
| Colour: | Red |
| Key type: | KAC Manal Call Point test & reset key |
| Materials housing: | Polycarbonate, ABS |
| Detection principle: | Operation of a switch |
| Approvals: | DNV.GL, MED |
| Analogue value nominal: | 16 |
| Alarm level analogue value: | 64 |
| Protocol voltage: | 5 to 9V peak to peak |
| Quiescent current: | 100μA (tested at 24V dc) |
| Power-up surge current: | 1mA |
| Max. power-up time: | 1 second |
| Polarity: | L1 & L2 are polarity sensitive |
| Humidity: | 0 - 95% (no condensation or icing) |
| Operating temperature: | -20 to 60°C |
| IP Rating: | IP24D |
| Warranty: | 10 year |
