Apollo XP95 Open-Area VAD Cat.C - White Body (White Flash) (C-3-8) (55000-745APO)
SKU
55000-745APO
£46.26
£38.55
Apollo 55000-745XP95 Open-Area VAD Cat.C - White Body (White Flash) (C-3-8) (55000-745APO)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Apollo XP95 Open-Area VAD Cat.C - White Body (White Flash) (C-3-8) (55000-745APO)
The Apollo XP95 Open-Area Visual Alarm Device (VAD) Cat. C (55000-745APO) has been designed specifically for indoor use and supplements sounders placed in areas where they may not necessarily be heard. Ceiling mount.
Key Features of the 55000-745APO |
|---|
|
> White body, white flash
> High intensity LEDs > EN 54-23 Compliant Category C. VAD > Coverage C-3-8 > Flash rate 0.5Hz > Fault signal if LED check failed > Wide angle of visibility > Synchronised flash rates with the Apollo Protocol > 10 year warranty |
| Brand | Apollo Fire Detectors |
|---|---|
| Manufacturer Part No. | 55000-745APO |
| Primary Power Source | 24V DC |
| System Type | Addressable |
| Protocol Compatibility | Apollo XP95, Apollo Discovery, Apollo CoreProtocol |
| Colour | White |
| Warranty | 10 Years |
Write Your Own Review
FAQ’s for Apollo XP95 Open-Area VAD Cat.C - White Body (White Flash) (C-3-8) (55000-745APO)
No questions yet. Be the first to ask the question!
Product Specification for Apollo XP95 Open-Area VAD Cat.C - White Body (White Flash) (C-3-8) (55000-745APO)
| Code: | 55000-745APO |
| Description: | Apollo 55000-745 XP95 Open-Area VAD Cat.C - White Body (White Flash) (C-3-8) |
| Dimensions: | Dia:100mm x H:50mm (58mm with XPERT7 mounting base) |
| Coverage class: |
C-3-8 |
| Flash colour: |
White |
| Flash rate: |
0.5 Hz |
| Digital Communications: |
XP95, Discovery and CoreProtocol compatible |
| Supply voltage: | 17 V - 28 V dc (polarity sensitive) |
| Power up surge current: |
1.5 mA |
| Quiescent: | 280 μA |
| Alarm current (LED on): |
12 mA |
| Operating temperature: | -10 to +55°C |
| Relative humidity: | 0 to 95% non-condensing or icing |
| IP rating: | IP54 (when used with Part No.45681-210, Part No. 45681-284 or Part No. SA5000-200 Mounting Base) IP55 (when used with the Deckhead Mounting Box Part No. 45681-217) |
| Material: | Fire retardant polycarbonate |
| Colour (body): | White |
| Vibration, impact & shock: | EN54-23 |
| Approvals / Standards: | EN 54-23, CPR, LPCB and VdS |
| Weight: | 105g |
