Aico YO3 High Output Remote Sounder
Discontinued
Alternative Products
Product Details for Aico YO3 High Output Remote Sounder
The Aico YO3 High Output Remote Sounder is 230V AC mains powered and suitable for security, fire and industrial applications.
It may be connected into the alarm system through the use of a compatible relay base or module, such as the Ei428 and the Ei218RBU. There are 32 different selectable tones that can be changed using the 6-way DIL switch, which will sound at 90-100dB(A) when activated. Constructed from sturdy, flame retardant moulded ABS plastic and stainless steel screws, it is IP66 rated and suitable for indoor and outdoor use. The IP66 rating means that the unit is protected from dust ingress and high pressure water jets from any direction. It is possible to mount the sounder using either the exterior lugs or internal BESA compatible fixing positions, and stainless steel fixing are supplied with the product.
It is CE marked and has a manufacturer's warranty period of 5 years.
Key Features of the YO3 |
|---|
|
> - 230V AC mains powered
- 32 selectable tones
- 100dB(A) at 1m
- Flame retardant ABS construction
- Suitable for indoor and outdoor use
- IP66 weatherproofing
- Fixings supplied
|
| Brand | Aico |
|---|---|
| Manufacturer Part No. | YO3 |
FAQ’s for Aico YO3 High Output Remote Sounder
Product Specification for Aico YO3 High Output Remote Sounder
| Manufacturer: | Aico |
| Product Code: | YO3 |
| Dimensions: | H:85mm W:85mm D:85mm |
| Product Weight: | 370g |
| Sound Output: | 100dB(A) at 1m +/- 3dB |
| Tones: | 32 (UKOOA/PFEER compliant) |
| Power Supply: | 230V AC, 15mA power consumption |
| Operating Temperature Range: | -25°C to +55°C |
| Operating Humidity Range: | 90% at 20°C |
| Approvals: | IP66 Rated CE Marked |
| Manufacturer's Warranty Period: | 5 years |
