Advanced Damper Interface Module - Boxed (Apollo Protocol) (MXP-046-BX1)
SKU
MXP-046-BX1
£579.19
£482.66
Advanced MXP-046-BX1 Damper Interface Module - Boxed (Apollo Protocol)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Advanced Damper Interface Module - Boxed (Apollo Protocol) (MXP-046-BX1)
The Advanced MXP-046-BX1 Damper Interface is a boxed loop driven device that utilises the Apollo protocol. The device is a fully monitored interface providing confirmation of the damper open and closed positions.
For use with dampers that are normally held open. Fail-safe operation only applicable to electrically opened & mechanically closed dampers.
Compatibility
Use with dedicated damper panels using Apollo protocol devices MxPro 5 series fire panels require version 050-05a (or higher) program to use with Apollo protocol devices PC configuration program must be 6.20 (or higher) to support damper interface units.
Key Features of the MXP-046-BX1 |
|---|
|
> Damper motor drive and limit switch monitoring integrated into a single unit
> Dual limit switch inputs for confirmation of damper-fully-open, and damper-fully-closed positions > Selectable monitoring on switch inputs to prevent short circuits in the wiring from giving false position readings > Fail-safe options in case of data errors in the communications loop |
| Brand | Advanced Electronics |
|---|---|
| Manufacturer Part No. | MXP-046-BX1 |
| Primary Power Source | 24V DC |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Advanced Damper Interface Module - Boxed (Apollo Protocol) (MXP-046-BX1)
No questions yet. Be the first to ask the question!
Product Specification for Advanced Damper Interface Module - Boxed (Apollo Protocol) (MXP-046-BX1)
| Enclosure Dimensions H x W x D mm | 300 x 200 x 150 - Steel IP66 |
| Colour | RAL 7032 Light Grey |
| Weight | 4Kg |
| PCB Dimensions H x W x D mm | 35 x 142 x 70 |
| Operating Temperature | -5°C to 40°C |
| Relative Humidity | 95% non-condensing (maximum) |
| Mains Supply | 230V AC, 50Hz (+10%,-15%), 30mA (plus motor load) |
| Motor Switch Rating | 1.0A |
| Fuse (PCB) | T3.15H250V |
| Fuse (Fuse terminal block) | T3.15H250V |
| Data loop current | 1.6mA |
