Advanced GO Single Loop Fire Alarm Panel (Argus Vega Protocol) (GO1V)
Product Details for Advanced GO Single Loop Fire Alarm Panel (Argus Vega Protocol) (GO1V)
The Advanced GO1V is a single-loop addressable fire alarm control panel, compatible with Argus Vega protocol devices and supports up to a maximum of 50 addresses.
The GO series from Advanced are cutting-edge fire control panels that transform non-networked single-loop fire alarm systems. With a host of enhancements to critical safety features, the innovative design retains all the advantages and user-friendly operation of an advanced fire alarm control panel.
Experience a whole new level of efficiency with the redesigned control panel layout, featuring an ergonomic design that seamlessly integrates with the high-resolution, high-contrast, graphical LCD display. The tactile keypad enables quick and intuitive select-and-click programming, facilitating faster engineer configuration and effortless end-user operation.
Choose between two performance options: Go and Go+. Each option offers a different maximum number of configurable addresses, allowing for greater flexibility in site-specific installations.
One of the notable functional improvements is the inclusion of integral zonal LEDs, enabling instant identification of alarm locations. This feature ensures compliance with BS5839 standards without the need for a separate LED zone card, saving you costs.
The new PCB integrates both the control panel and peripherals onto a single board, incorporating the latest high-speed microprocessor technology. This advancement enables the Go series panels to operate nine times faster than the MxPro4, providing unparalleled performance.
Take advantage of powerful cause-and-effect programming and enhanced trace diagnostics, making the panels suitable for a wide range of site applications, from small to medium systems.
Configuring the Go series panels is a breeze. They can be fully programmed on-site using the control panel display or the updated, easy-to-use PC Configuration Tool. Enjoy seamless customisation and adaptability to meet your specific requirements.
Key Features of the GO1V |
|---|
|
> Argus Vega protocol
> Graphical LCD user interface, LED indicators and push buttons > Installer-friendly Auto-learn, Loop detection and On-board scope facility > 500 fire + 5000 general event logging, with advanced diagnostic precision to aid installation and fault-finding > Integral 15 Zone LEDs ensures compliance with BS5839, with 35 additional software indication zones > Uses a new Configuration Tool with Office 365 appearance offering better graphics and easier functions for programming > Two on-board Sounder outputs, three on-board Relay outputs > Optional 3 monitored input/outputs for Fire/Fault routing (with P-Bus adaptor and routing card) for full EN54 compliance when connected to an Alarm Receiving Centre. > Dedicated USB Type B port for direct PC connection > Ethernet connectivity to AdvancedLive, which provides remote notification and panel management > Innovative 'no hinge' removable door and hangable chassis for easier installation > Employing an identical monitoring feature as the Mx-5000 series, the Go series meets the requirements of EN54-13 (2005) Clauses 5.3.4.1 and 5.3.4.2 (partial open & short circuits) for optimal fire system performance and complete peace of mind |
| Brand | Advanced Electronics |
|---|---|
| Manufacturer Part No. | GO1V |
| Product Series | GO |
| Primary Power Source | Mains Powered (230V) |
| System Type | Addressable |
| Number of Loops (Fitted) | 1 |
| Max No. of Loops Possible | 1 |
| Number of Zones | 50 |
| Protocol Compatibility | Argus Vega |
| Colour | Grey |
| Warranty | 3 Years |
FAQ’s for Advanced GO Single Loop Fire Alarm Panel (Argus Vega Protocol) (GO1V)
Product Specification for Advanced GO Single Loop Fire Alarm Panel (Argus Vega Protocol) (GO1V)
| Protocols | Argus Vega |
| Number of Loops | 1 |
| Loop Current | 500mA max |
| Number of Fire Zones | 50 max |
| Sounder Outputs | 2 x 1A Programmable (1A total) |
| Relay Outputs (Programmable) | 3 x 1A 30VAC/DC (max) to 10mA 5V (min) |
| Auxiliary Output | 24V DC, 100mA (With GOP-001 Fitted) |
| Display | LCD White backlit 240 x 64 Graphical LCD |
| Programmable Inputs | 1 x Key Switch, 1 x monitored |
| USB | USB type B interface for PC connection |
| Network | None |
| Ethernet | 10-Base-T, 100-Base-T |
| Event Log | 5000 Events with Diagnostics + 500 Fire Events |
| Enclosure | Steel IP30 RAL7035 |
| Dimensions H x W x D mm | 345 x 345 x 87 |
| Weight (excluding batteries) | 4Kg |
| Temperature Range | -5°C to 40°C |
| Humidity (RH) | 95% max |
| Cable Entries | 14 x 20mm knockouts at top |
| AC Supply | 220-240V, 50 – 60 Hz, 1.0A max |
| Safety | EN62368-1, Class 1, Pollution Degree 2, Overvoltage Category II |
| Battery Capacity | 24V 4Ah Internal (min), 24V 7Ah Internal (max) |
| Charging Current | 0.35A Temp Compensated |
| Deep Discharge Cut-off | 19.5V |
| Power Supply | On-board 24V DC, 1.5A High Efficiency Off-Line Switched Mode |
| Output Voltage | 18.0V – 28.0V |
| Ripple (Vpkpk) | Up to 1.0V |
| Max Battery Ohms | 1.8Ω ± 0.1 Ω |
| Imax(a), Imax(b) | 1.15A, 1.5A |
