Advanced ExGo Emergency Stop Button (EN12094-3 Type B) (EXP-011)
SKU
EXP-011
£71.80 £59.83
Advanced ExGo Emergency Stop Button (EN12094-3 Type B) (EXP-011)
Product Details for Advanced ExGo Emergency Stop Button (EN12094-3 Type B) (EXP-011)
The Advanced EXP-011 Emergency Stop Button (EN12094-3 Type B) incorporates a momentary (non-latching) push button switch. Break the glass and press and hold the button to activate the circuit.
The buttons are easy to wire, and multiple units can easily be connected together in series on an input circuit. They are compatible with the ExGo gas extinguishing panel and remote status indicator panel input circuits.
Installation requires EXP-005 switch EOL for terminating the switch input circuits.
Key Features of the EXP-011 |
|---|
| > Emergency Stop Button EN12094-3 Type B > Blue > Incorporates a momentary (non- latching) push button switch > Break glass and hold button to activate circuit > Aluminium die-cast housing with door aperture angle >180 deg > Replaceable door label > Red LED activation indication > Replaceable standardised glass plate (EXS-005) > Button housing can be opened with key (EXS-003) > Multiple units can be connected together in series on an input circuit > Compatible with ExGo gas extinguishing panel and remote status indicator panel input circuits > Installation requires EXP-005 switch EOL for terminating the switch input circuits > EN12094-3:2003 and EN54-17 approved |
| Brand | Advanced Electronics |
|---|---|
| Manufacturer Part No. | EXP-011 |
| Product Range / Series | ExGo |
| Primary Power Source | 24V DC |
| System Type | Conventional |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Advanced ExGo Emergency Stop Button (EN12094-3 Type B) (EXP-011)
No questions yet. Be the first to ask the question!
Product Specification for Advanced ExGo Emergency Stop Button (EN12094-3 Type B) (EXP-011)
| Product Code: | EXP-011 |
| Product description: | Emergency Stop Button (EN12094-3 Type B) |
| Dimensions: | W:126mm x H:126mm x D:35mm |
| Approvals: | 0786-CPD-20363 |
| Protection Class: | IP43 |
| Temperature: | -20o to +60oC (continuous operation) -25o to +70oC (max 12 hours) |
| Humidity: | 95% max (non condensing) |
| Activation Module: | EXP-005 Module |
| Cable glands: | 2 x 20mm (top or bottom entry) |
| Weight: | 420g |
