Advanced ExGo Manual Release Button (EN12094-3 Type B) (EXP-010)
SKU
EXP-010
£70.19
£58.49
Advanced ExGo Manual Release Button (EN12094-3 Type B) (EXP-010)
Available to Order
This item is not currently in stock at our main warehouse, but it is available to backorder or may be sent directly from the manufacturer. Contact us for lead time.
Product Details for Advanced ExGo Manual Release Button (EN12094-3 Type B) (EXP-010)
The Advanced EXP-010 Manual Release Button (EN12094-3 Type B) incorporates a latching push button switch. Break the glass and press the button to activate the circuit. Press the reset switch to deactivate.
The buttons are easy to wire, and multiple units can easily be connected together in series on an input circuit. They are compatible with the ExGo gas extinguishing panel and remote status indicator panel input circuits.
Installation requires EXP-005 switch EOL for terminating the switch input circuits.
Key Features of the EXP-010 |
|---|
|
> Manual Release Button EN12094-3 Type B
> Yellow > Incorporates a latching push button switch > Break glass and press button to activate circuit > Press reset switch to deactivate > Aluminium die-cast housing with door aperture angle >180 deg > Replaceable door label > Red LED activation indication > Replaceable standardised glass plate (EXS-005) > Button housing can be opened with key (EXS-003) > Multiple units can be connected together in series on an input circuit > Compatible with ExGo gas extinguishing panel and remote status indicator panel input circuits > Installation requires EXP-005 switch EOL for terminating the switch input circuits > EN12094-3:2003 and EN54-17 approved |
| Brand | Advanced Electronics |
|---|---|
| Manufacturer Part No. | EXP-010 |
| Product Series | ExGo |
| Primary Power Source | 24V DC |
| System Type | Conventional |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for Advanced ExGo Manual Release Button (EN12094-3 Type B) (EXP-010)
No questions yet. Be the first to ask the question!
Product Specification for Advanced ExGo Manual Release Button (EN12094-3 Type B) (EXP-010)
| Product Code: | EXP-010 |
| Product description: | Manual Release Button (EN12094-3 Type B) |
| Dimensions: |
W:126mm x H:126mm x D:35mm |
| Approvals: |
0786-CPD-20251 |
| Protection Class: | IP43 |
| Temperature: |
-20o to +60oC (continuous operation) -25o to +70oC (max 12 hours) |
| Humidity: |
95% max (non condensing) |
| Activation Module: |
EXP-005 Module |
| Cable glands: |
2 x 20mm (top or bottom entry) |
| Weight: | 420g |
